USER INFORMATION

Congratulations on choosing a Claypaky product!

We thank you for your custom.

Please note that this product, as all the others in the rich

Claypaky range, has been designed and made with total quality

to ensure excellent performance and best meet your

expectations and requirements.

The Xtylos is a compact beam moving light with unique optical and

chromatic characteristics, making use of a tailor-made laser source

(Patent Application filed). This laser source, lasting for 10,000

hours, is enclosed in a reliable, safe and fully sealed module and it

is the powerful engine of an incredible array of colors.

The beam aperture is less than 2° and it can be decreased

further to 0.5°. The Xtylos uses laser technology with RGB

additive color mixing. In contrast to the subtractive mixing used

with discharge lamps, colored light beams are as bright as a

white light beam! The range of effects features two gobo wheels

- with 7 rotating gobos and 12 fixed gobos (including 7 beam

diameter reducers) - a wheel with 3 prisms, and a sixteen facet

prism on a dedicated channel which can be overlapped with the

prism wheel.

The Xtylos is definitely the most dynamic light on the market. It

is the first moving head light with a laser light source, and this

opens up new, surprising prospects for the development of the

entire entertainment lighting world.

INDEX

ENGLISH

Page Contents

2 1. Safety information

4 2. Unpacking and preparation

7 3. Installation and start-up

73.1 Installing the fixture

7 3.2 Connecting to mains supply

8 3.3 Connecting the control signal line: DMX / Art-Net

8 3.4 Switching on the fixture and basic SetUp

10 4. Dimensions

CJ3000

XTYLOS
