Pagina 1/13
Manual Plasma
Cutting Inverters
1300 654 674
I
www.cigweld.com.au
AEQPLA Rev 2
Genuine (True) cut capacity (mild steel).
Cut speed of 250mm/min with an excellent
smooth cut surface and little or no dross
with no need for grinding or rework.
Power Factor Correction
Warranty period
(refer Warranty Schedule for full details)
Victor Technologies Professional:
When cutting and welding is your business
At Victor Technologies we distinguish ourselves from our
competition through superior featured, dependable
products, technical innovation and excellence in customer
service and technical support.
Our Professional Series Manual Plasma Cutting Inverter
range is proof of this commitment to deliver quality
equipment that exceeds expectations. A wealth of features
and options make this equipment the perfect choice for the
serious cutting and welding professional.
The Victor Technologies Manual Plasma range
The new and improved CUTMASTER® TRUE™ Series has
been designed with the premise that recommended cut
capacity should reflect the TRUE cut capacity.
The TRUE Cut Series eliminates the concept of having to
purchase a machine larger than you actually need. With the
introduction of the CUTMASTER TRUE Series, a 10mm
recommended capacity machine will cut 10mm mild steel.
No exceptions.
Combine all these market leading features into a compact,
efficient, portable inverter design with a full range of
packaged accessories and you have the ultimate fully
featured professional range for construction, mining,
shipbuilding,
rental hire and other industrial applications.
Introduction
CONTENTS
3mm01 RETSAMTUC
4mm21 RETSAMTUC
5mm02 RETSAMTUC
6mm52 RETSAMTUC
7mm53 RETSAMTUC
8mm04 RETSAMTUC
9002 KAP
01™hcroT1
Manual Plasma Technical Specifications 11
120 A
OU PUT T
415
V
3
PHASE
3
YEAR
*
KEY TO ICONS
©2012 Victor Technologies. All rights reserved.
Maximum output current
Input voltage
Number of phases (input)
Manual Plasma Cutting Inverters
3
Ordering Information
CUTMASTER 10mm plant 1-4730-6
Plant contents
Cutmaster 10mm power source;
SL60 6.1m hand cutting torch, work lead (fitted),
consumables starter kit; shoulder strap;
operation manual
Optional Accessories
Circle cutting guide OTD7/3291
Roller & radius cutting guide OTD7/7501
ATC 7.6m torch lead extension OTD7/7545
Single stage air filter kit 7-7507
The new Cutmaster True Series 10mm manual plasma is an inverter based system
specifically designed to provide excellent cutting and beveling performance on
materials up to 10mm thick. The system also incorporates features such as auto-
pilot re-start, power factor correction and the industry renowned SL60 1Torch®
for superior durability and consumable life.
These features combined with a three year limited warranty make this the ideal
unit for sheetmetal cutting applications, auto body repairs and light fabrication.
Cutting Capacity Terminology
Genuine (True) Cut Cutting speed of 250 mm/min with an excellent smooth
cut surface and little or no dross with no need for
grinding or rework
Severance Cut Cutting speed of less than 100 mm/min with rippled cut
surface and significant dross
30 A
OUT TPU
240
V
1
PHASE
3
YEAR
*
Plant Part No. 1-4730-6
TMAST R
®
1 mm
Cutting Capacity
Genuine (True) Cut 10mm
Severance Cut 12mm
Pierce Rating 5mm
NOTE: Cutting capacity data based on mild steel.
Specifications
Supply Voltage
240 volt (+/- 15%), 1 phase, 50/60Hz
10A input plug fitted; Power Factor Correction
Minimum Recommended Generator
3.8kVA
Maximum Output Current
30 amps
Duty Cycle (@ 40˚C)
30 amps @ 40%
Warranty
Power source - 3 years; Torch - 1 year*
Power Source Weight
14kg
Dimensions (Power Source)
300 H x 175 W x 490 L mm
*Refer to Warranty Schedule for full details
