Pagina 1/16

I N S T A L L A T I O N I N S T R U C T I O N S

Above Cart/Ceiling Above Wall

Below Cart/Ceiling Below Wall

(FCA811 shown)

Fusion™ Above/Below Accessory Shelf

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

FCA810/811

FCA810/811 Installation Instructions

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and

subsidiaries (collectively “Milestone”), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

DEFINITIONS

MOUNTING SYSTEM: A MOUNTING SYSTEM is the

primary Chief product to which an accessory and/or component

is attached.

ACCESSORY: AN ACCESSORY is the secondary Chief

product which is attached to a primary Chief product, and may

have a component attached or setting on it.

COMPONENT: A COMPONENT is an audiovisual item

designed to be attached or resting on an accessory or mounting

system such as a video camera, CPU, screen, display,

projector, etc.

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all accessories are

properly assembled and installed using the instructions

provided.

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the weight mounted to

the FCA810/811 shelf does not exceed 10 lbs (4.5 kg).

WARNING: Use of this accessory will decrease the weight

capacity of the mounting system to which it is attached by the

combined weight of the accessory and all components

supported by this accessory! See Figure below for reference.

WARNING: Use this accessory only for its intended use as

described in these instructions. Do not use attachments not

recommended by the manufacturer.

WARNING: Never operate this accessory if it is damaged.

Return the accessory to a service center for examination and

repair.

WARNING: Do not use this product outdoors.

WARNING: RISK OF INJURY TO PERSONS! Do not use

this accessory to support video equipment such as

televisions or computer monitors.

--SAVE THESE INSTRUCTIONS--

(weight capacity of mounting system) minus

(*weight of FCA810/811 shelf + shelf components)

10 lbs (4.5 kg)

*FCA810/811 shelf weighs 11.5 lbs (5.22 kg)

weight capacity of accessory

Installation Instructions FCA810/811

DIMENSIONS - FCA810

36.4

924.9

OVERALL MAX

23.4

594.7

OVERALL MIN

17.8-19.5

[452.1-494.0]

MIN RANGE

FUSION WALL ABOVE MOUNT SETUP

(*)NOTES:

TYPICAL FUSION INTERFACES ARE 0.5" [12.7] DEEP

•

19.5-29.4

[494.0-745.0]

INTERMEDIATE

RANGE

29.5-30.9

[750.3-784.9]

MAX RANGE

18.0-19.7

FUSION WALL BELOW MOUNT SETUP

(*)NOTES:

TYPICAL FUSION INTERFACES ARE 0.5" [12.7] DEEP

•

19.7-29.5

[499.1-750.3]

INTERMEDIATE

RANGE

Product specificaties

Merk:	Chief
Categorie:	Niet gecategoriseerd
Model:	FCA811
Kleur van het product:	Zwart
Gewicht:	5000 g
Breedte:	355.6 mm
Soort:	Plank
Geschikt voor schermmaten:	62 - 100 "
Certificering:	TAA
Hoogte verstelbaarheidsbereik:	457.2 - 782.3 mm
