Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53330016-01Printed in U.S.A.Form 33CS-68SIPg 15-11Replaces: 33CS-67SI

Installation, Start-Up and

Configuration Instructions

Part Number 33CSPREMLK

CONTENTS

Page

SAFETY CONSIDERATIONS. . . . . . . . . . . . . . . . . . . . . . 1

GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30

Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PremierLink Controller Hardware. . . . . . . . . . . . . . . . . 2

Field-Supplied Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 2

•SPACE TEMPERATURE (SPT) SENSOR

•SUPPLY AIR TEMPERATURE (SAT) SENSOR

•INDOOR AIR QUALITY CO

2

SENSOR

•OUTDOOR AIR QUALITY CO

2

SENSOR

•RELATIVE HUMIDITY SENSOR

•OUTDOOR AIR TEMPERATURE SENSOR

•OUTDOOR AIR ENTHALPY SWITCH/RECEIVER

•FILTER SWITCH

Mount PremierLink Control. . . . . . . . . . . . . . . . . . . . . . . 3

•LOCATION

•MOUNTING

PremierLink Controller Inputs and Outputs . . . . . . 3

Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Install Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

•SPACE TEMPERATURE (SPT) SENSOR

INSTALLATION

•SUPPLY AIR TEMPERATURE (SAT) SENSOR

INSTALLATION

•INDOOR AIR QUALITY CO

2

SENSOR

INSTALLATION

•OUTDOOR AIR QUALITY CO

2

SENSOR

INSTALLATION

•HUMIDITY SENSOR (WALL-MOUNTED) INSTAL-

LATION

•OUTDOOR AIR TEMPERATURE SENSOR

•FACTORY-INSTALLED CONTROLLER

Connect Discrete Inputs . . . . . . . . . . . . . . . . . . . . . . . . 19

Connect to CCN Communication Bus . . . . . . . . . . . 19

•COMMUNICATIONS BUS WIRE SPECIFICATIONS

Enthalpy/Switch Receiver . . . . . . . . . . . . . . . . . . . . . . . 23

•OUTDOOR ENTHALPY CONTROL

•DIFFERENTIAL ENTHALPY CONTROL

Enthalpy Sensors and Control . . . . . . . . . . . . . . . . . . 25

•OUTDOOR AIR ENTHALPY SENSOR/

ENTHALPY CONTROLLER

•RETURN AIR ENTHALPY SENSOR

Economizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

•Q769B ADAPTER

•Q769C ADAPTER

Economizer with 4 to 20 mA Actuator . . . . . . . . . . . 28

•DRIVE DIRECTION

•SWITCH SELECTION

•WIRING

START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-37

Page

Perform System Check-Out . . . . . . . . . . . . . . . . . . . . . 30

Initial Operation and Test . . . . . . . . . . . . . . . . . . . . . . . 30

Sequence of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . 30

•THERMOSTAT MODE

•CCN SENSOR MODE

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-55

Points Display Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Thermostat Control Input Screen. . . . . . . . . . . . . . . . 40

Alarm Service Configuration Screen . . . . . . . . . . . . 40

Controller Identification Screen . . . . . . . . . . . . . . . . . 41

Holiday Configuration Screen. . . . . . . . . . . . . . . . . . . 41

Occupancy Configuration Screen . . . . . . . . . . . . . . . 41

Set Point Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Service Configuration Selection Screen. . . . . . . . . 43

PremierLink Configuration Screen . . . . . . . . . . . . . . 47

Occupancy Maintenance Screen . . . . . . . . . . . . . . . . 49

Primary Maintenance Screen. . . . . . . . . . . . . . . . . . . . 50

System Pilot™ Maintenance Table . . . . . . . . . . . . . . 53

System Pilot Alternate Maintenance Table. . . . . . . 54

APPENDIX A — CCN SCREENS. . . . . . . . . . . . . . 56-59

SAFETY CONSIDERATIONS

SAFETY NOTE

Air-conditioning equipment will provide safe and reliable

service when operated within design specifications. The

equipment should be operated and serviced only by autho-

rized personnel who have a thorough knowledge of system

operation, safety devices and emergency procedures.

Good judgement should be used in applying any manufac-

turer’s instructions to avoid injury to personnel or damage to

equipment and property.

WARNING

Disconnect all power to the unit before performing mainte-

nance or service. Unit may automatically start if power is

not disconnected. Electrical shock and personal injury

could result.

CAUTION

An individual field-supplied 24-vac power transformer is

recommended for each PremierLink controller. If the unit

transformer is used but does not have enough power, dam-

age to equipment may result. The field-supplied trans-

former must be less than 100 VA to meet UL (Underwriters

Laboratories) Class 2.

PREMIERLINK™

Retrofit Rooftop Controller

Version 3.x
