Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53300202-01Printed in U.S.A.Form 30XA-27SIPg 1 9-21Replaces: 30XA-26SI

Installation Instructions

CONTENTS

Page

SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . .1

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Step 1 — Inspect Shipment . . . . . . . . . . . . . . . . . . . .2

Step 2 — Place, Mount, and Rig the Unit . . . . . . . . .2

•PL

ACING UNIT

•MOUNTING UNIT

•RIGGING UNIT (SEE FIG. 27-29)

Step 3 — Make Refrigerant, Cooler Fluid and Drain

Piping Connections . . . . . . . . . . . . . . . . . . . . . . .88

•30XA501 UNIT ASSEMBLY

•GENERAL

•FLOODED COOLER UNITS

•DX COOLER UNITS

•PREPARATION FOR YEAR-ROUND OPERATION

Step 4 — Fill the Chilled Water Loop . . . . . . . . . .108

•WATER SYSTEM CLEANING

•WATER TREATMENT

•SYSTEM PRESSURIZATION

•FILLING THE SYSTEM

•SET WATER FLOW RATE

•PUMP MODIFICATION/TRIMMING

•PUMP VFD

•SENSORLESS CONTROL (CLOSED LOOP), ACTIVE

SETUP 1

•REMOTE SENSOR (CLOSED LOOP), ACTIVE SETUP 2

•REMOTE CONTROLLER (OPEN LOOP), ACTIVE SETUP

3

•FREEZE PROTECTION

•PREPARATION FOR WINTER SHUTDOWN

Step 5 — Make Electrical Connections . . . . . . . . .113

•POWER SUPPLY

•FIELD POWER CONNECTIONS (SEE FIG. 61)

•POWER WIRING

•FIELD CONTROL POWER CONNECTIONS

•CCN COMMUNICATION BUS WIRING

•NON-CCN COMMUNICATION WIRING

•FIELD CONTROL OPTION WIRING

•DUAL CHILLER LEAVING WATER SENSOR

Step 6 — Install Accessories . . . . . . . . . . . . . . . . .136

•ENERGY MANAGEMENT MODULE

•REMOTE ENHANCED DISPLAY

•LOW AMBIENT TEMPERATURE OPERATION

•MINIMUM LOAD ACCESSORY

•UNIT SECURITY/PROTECTION ACCESSORIES

•COMMUNICATION ACCESSORIES

•SERVICE OPTIONS

Step 7 — Leak Test Unit . . . . . . . . . . . . . . . . . . . . .136

St

ep 8 — Refrigerant Charging . . . . . . . . . . . . . . . .136

•DEHYDRATION

•REFRIGERANT CHARGE

Step 9 — Optional BACnet Communication Wiring .137

•MS/TP WIRING RECOMMENDATIONS

SAFETY CONSIDERATIONS

Installing, starting up, and servicing this equipment can be hazard-

ous due to system pressures, electrical components, and equip-

ment location. Only trained, qualified installers and service me-

chanics should install, start up, and service this equipment.

When working on the equipment, observe precautions in the liter-

ature, and on tags, stickers, and labels attached to the equipment.

•Follow all safety codes.

•Wear safety glasses and work gloves.

•Use care in handling, rigging, and setting bulky equipment.

WARNING

DO NOT USE TORCH to remove any component. System

contains oil and refrigerant under pressure.

To remove a component, wear protective gloves and goggles

and proceed as follows:

a.Shut off electrical power to unit.

b.Recover refrigerant to relieve all pressure from system

using both high-pressure and low pressure ports.

c.Traces of vapor should be displaced with nitrogen and

the work area should be well ventilated. Refrigerant in

contact with an open flame produces toxic gases.

d.Cut component connection tubing with tubing cutter and

remove component from unit. Use a pan to catch any oil

that may come out of the lines and as a gage for how

much oil to add to the system.

e.Carefully un-sweat remaining tubing stubs when neces-

sary. Oil can ignite when exposed to torch flame.

Failure to follow these procedures may result in personal inju-

ry or death.

WARNING

Electrical shock can cause personal injury and death. Shut off

all power to this equipment during installation. There may be

more than one disconnect switch. Tag all disconnect locations

to alert others not to restore power until work is completed.

AquaForce

®

30XA080-501

Air-Cooled Liquid Chillers
