Operating Instructions

Two Stage

Air Compressors

IN561200AV 7/11© 2011 Campbell Hausfeld/Scott FetzerFor parts, product & service information

visit www.CH-Commercial.com

1-888-606-5587

Series CE7000, CE8000 and CE9000

Table of Contents

Introduction � � � � � � � � � � � � � � � � � � � � � � � � � �1

Safety Guidelines� � � � � � � � � � � � � � � � � � � � � �2

Safety Symbols� � � � � � � � � � � � � � � � � � � � � � � �2

Important Safety Information � � � � � � � � � �2

Getting To Know Your Compressor � � � � �4

Unpacking� � � � � � � � � � � � � � � � � � � � � � � � � � � �6

Installation � � � � � � � � � � � � � � � � � � � � � � � � � � �6

Operation � � � � � � � � � � � � � � � � � � � � � � � � � � 12

Maintenance� � � � � � � � � � � � � � � � � � � � � � � � 13

Troubleshooting Guide

New Installations� � � � � � � � � � � � � � � � � 15

Units in Service for a

Period of Time � � � � � � � � � � � � � � � � � � � 17

Limited Warranty� � � � � � � � � � � � � � � � � � � � 20

Introduction

The Campbell Hausfeld CE Series line

of air compressors are two stage, oil

lubricated reciprocating compressors�

There are two configurations - Shop Air

Series (basic) and Tire and Lube Series

(fully packaged)�

SHOP AIR SERIES MODELS INCLUDE:

•Compressorpump

•ASMEairreceiverwithsafetyvalve

•Electricmotororgasengine

•Starter

•Pressureswitch

TIRE AND LUBE SERIES MODELS

INCLUDE:

•AllofthefeaturesoftheShopAir

models

•Aircooledaftercooler

•Digitalhourmeter

•Automatictankdrain

•Lowoilguard

•Vibrationisolationpads

•Shut-offvalve

Quick Reference

RECOMMENDED OIL (2 OPTIONS)

Single viscosity SAE 30 ISO100 nondetergent compressor oil� Available from

CampbellHausfeld,partnumberST126700AV.

10W30 synthetic oil such as Mobil 1

®

�

OIL CAPACITY

CE7000 Series2 quarts

CE8000 Series4 quarts

CE9000 Series4-1/2 quarts

RETAIN THIS INFORMATION FOR FUTURE REFERENCE

Serial Number:

Model Number:

Date of Purchase:
