ASSEMBLY INSTRUCTIONS
ITEM NO:BO-2899FL-3L
CAREFULLY UNPACK AND PLACE ALL PARTS ON A SMOOTH SURFACE.
IMPORTANT SAFETY INSTRUCTIONS:
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER) AS A
FEATURE TO REDUCE THE RISK OF ELECTRIC SHOCK. THIS PLUG WILL FIT IN A POLARIZED OUTLET
ONLY ONE WAY. IF IT DOES NOT FIT FULLY IN THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT
FIT, CONTACT A QUALIFIED ELECTRICIAN. NEVER USE WITH AN EXTENSION CORD UNLESS THE PLUG
CAN BE FULLY INSERTED. DO NOT ALTER THE PLUG.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Use MAX 3 x 60 Wattage type A bulb (bulb not included)
1.INSERT POLE (A) INTO POLE (B) USING HEX SCREW (C) BY ALLEN WRENCH
TO TIGHTEN .
2.UNSCREW WASHER (G) AND NUT (H) FROM THREAD (F) ON POLE (D) .
3.ADJUST THREAD (F) ON POLE (D) TO DESIRED HEIGHT .
4.INSERT POLE (D) INTO THE BASE (E) .
MAKE SURE THE BASE (E) AND THE SOCKET
ARE AT THE SAME DIRECTION,THEN TIGHTEN
WITH WASHER (G) & NUT (H) USING A WRENCH.
5.CONNECT MALE PLUG (I) INTO FEMALE PLUG
(J), INSERT LAMP ARM (B) INTO POLE (D) AND
TIGHTEN WITH SCREW (K) USING A SCREW
DRIVER .
6.PLACE SHADE (M) ONTO SOCKET (L) ,THEN
USE THE SOCKET RING (N) CLOCKWISE
TO TIHGTEN.
7.INSTALL BULB (NOT INCLUDED) INTO
THE SOCKET .
8.INSERT THE POWER PLUG INTO AN
OUTLET AND ENJOY !!
A
B
C
D
E
F
G
H
I
L
N
M
J
K
Product specificaties
| Merk: | Cal Lighting |
| Categorie: | Verlichting |
| Model: | Lyndon BO-2899FL-3L |
