Bekijk gratis de handleiding van Cadel River Idro 16 (52 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 2 mensen en kreeg gemiddeld 3.7 sterren uit 1.5 reviews. Heb je een vraag over Cadel River Idro 16 of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/52
INSTALLER MANUAL
PELLET THERMOSTOVE
EN
Original Instructions | ©2022 CADEL srl | All rights reserved - Tutti i diritti riservati
new
IDROPRINCE
3
12 - RIVER
IDRO 16T2 - 23T2 - 23H
2
O T2
MIRA 16T2 - 22T2
TESIS 16 AIRTIGHT T2 - 23 AIRTIGHT T2
MAYA IDRO 16T2 - 24T2
IDROPRINCE 12 - RIVER IDRO T2 - TESIS Airtight T2 - MIRA T2 - MAYA idroT2
2
SUMMARY
1 MANUAL SIMBOLOGY .................................... 3
2 PACKAGING AND HANDLING ..........................3
2.1 PACKAGING .............................................................3
2.2 PREPARATION AND UNPACKING .............................3
2.3 STOVE HANDLING....................................................5
3 CHIMNEY FLUE .............................................5
3.1 PREPARING THE SMOKE EXPULSION SYSTEM ......... 5
3.2 CHIMNEY COMPONENTS .........................................5
3.3 SMOKE DUCT (SMOKE FITTING) ..............................6
3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................6
3.5 CHIMNEY POT ..........................................................7
3.6 MAINTENANCE ........................................................8
4 COMBUSTION AIR .........................................8
4.1 AIR INLET ................................................................8
4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER
INSTALLATION ...................................................................9
5 EXAMPLES OF INSTALLATION (DIAMETERS AND
LENGTHS TO BE SIZED) ......................................10
6 INSTALLATION ............................................11
6.1 INTRODUCTION .....................................................11
6.2 MINIMUM DISTANCES ........................................... 12
6.3 OVERALL DIMENSIONS .........................................13
6.3.1 RIVER IDRO (T2) 16 - 23 - 23 H
2
O DIMENSIONS .13
6.3.2 MIRA 16 -22 - TESIS 16 - 23 - (T2) AIRTIGHT
DIMENSIONS ......................................................................13
6.3.3 MAYA IDRO 16 - 23 DIMENSIONS ....................... 14
6.4 STOVE DOOR REMOVAL/INSTALLATION ................14
6.5 FITTING THE METAL FRAME OF RIVER IDRO 16-23-23
H
2
O ..............................................................................15
6.6 FITTING THE MAIOLICA FRAME OF RIVER- IDRO 16 -
23 - 23 H
2
O ....................................................................... 16
6.7 MAYA IDRO 16-24 FRAME ASSEMBLY ...................16
6.8 ASSEMBLING TESIS 16-23 AIRTIGHT + MIRA 16-22 .
..............................................................................18
6.9 ASSEMBLING THE TOP CLADDING AND BOTTOM
DOOR ..............................................................................18
6.10 ELECTRIC CONNECTION .........................................19
7 SMOKE OUTLET CONNECTION IDRO MAYA 16 - 24
.................................................................19
7.1 GENERAL WARNINGS ............................................19
7.2 REAR OUTLET CONNECTION ..................................19
7.3 TOP OUTLET CONNECTION IDRO MAYA 16 - 24 .....20
8 PLUMBING CONNECTION.............................20
8.1 PLUMBING SYSTEM CONNECTION.........................20
8.2 CONNECTION DIAGRAM RIVER IDRO 16 - 23 - MIRA
16-22 - TESIS 16-23 AIRTIGHT .........................................21
8.3 CONNECTION DIAGRAM RIVER IDRO 23 H
2
O ........22
8.4 CONNECTION DIAGRAM IDRO MAYA 16 - 24 ........22
8.5 3 BAR DISCHARGE VALVE ......................................23
8.6 WASHING THE SYSTEM .........................................23
8.7 FILLING THE SYSTEM .............................................23
8.8 WATER CHARACTERISTICS ....................................24
8.9 SYSTEM CONFIGURATION .....................................24
8.15 CONFIGURATION WITH STORAGE TANK AND
AUXILIARY WALL-MOUNTED BOILER (EXAMPLE) ...........33
8.15.1 SYSTEM WITH: PELLET STOVE CONNECTED TO A
STORAGE TANK WITH AUXILIARY WALL-MOUNTED BOILER 33
8.16 OPERATING MODE ................................................. 34
8.17 ELECTRICAL CONNECTIONS ................................... 34
9 SPECIAL MAINTENANCE ..............................35
9.1 INTRODUCTION .....................................................35
9.2 FUME CONDUIT CLEANING .................................... 36
9.3 SMOKE EXTRACTOR COMPARTMENT CLEANING ...36
9.4 CLEANING THE SMOKE EXTRACTION SYSTEM AND
GENERAL CHECKS ............................................................36
9.5 DOOR CLOSING FUNCTIONALITY PERIODIC CHECK 37
9.6 FUME PASSAGES CLEANING ..................................37
9.7 REPLACING THE OVERPRESSURE RELIEF VALVE FOR
THE COMBUSTION CHAMBER ..........................................38
10 BOILER HEAD CLEANING .............................39
10.1 FUME PIPES ANNUAL CLEANING ..........................40
10.2 GASKET REPLACEMENT ......................................... 40
11 IN CASE OF ANOMALY ..................................40
11.1 PROBLEM SOLVING ...............................................40
11.2 PROBLEM SOLVING (THERMOSTOVE) ...................43
12 TECHNICAL DATAS ......................................45
12.1 REPAIR INFORMATION ..........................................45
13 ELECTRONIC BOARD ...................................46
14 FEATURES ..................................................47
