1
C3235 Checkweigher
User Instructions
1 Introduction
The C3235 is a checkweighing scale for the rapid indication of over, under or acceptable weight
in a production environment. This manual covers the introduction to the unit, its use,
configuration and calibration.
1.1 Front Panel
Figure 1 shows the front panel of the unit. The front panel includes the display window,
the annunciators arrayed around the display, the four keys, and the bubble level.
Figure 1 C3235 Front Panel
NOTE: This product is rated to IP54. Care must be taken to ensure the main power plug does
not become wet. If the product is required to be used while plugged into the outlet, the
plug must either be located outside the wet area, or must be plugged into a socket
which provides suitable IP rating with the plug mated.
2
1.2 Keys and Annunciators
1.3 Display Messages
ZERO key. Press this key to turn the scale on and
zero the display.
TARE key. Press this key to tare the weight on the
scale. Also accepts the displayed item in the menu
structure or during numeric entry.
OFF key. Press this key to turn the scale off.
F key. Use this key to access the Configuration
menu. Also used in the menu to move between
choices.
dc.x.xx This is the voltage of the battery in volts.
------ This is displayed and a beep sounds when the scale is
overloaded. A weight more than 9 divisions over capacity
is and overload condition.
-BATLo- This is displayed when the battery voltage is low. The
scale can continue to be used for a while, but it is
advised to recharge the battery as soon as possible.
CAEnd This is displayed when calibration is finished.
Err-0 A zero point error has occurred.
C_End This is displayed when the battery is fully recharged.
