Extractor hood

DFS097K51 DFS067K51 DFS098K54 DFS068K54

[en] User manual and installation instructions

en Table of contents

You can find additional information and explanations online.

Scan the QR code on the title page.

Table of contents

INFORMATION FOR USE

1 Safety ........................................................................ 2

2 Avoiding material damage ..................................... 4

3 Environmental protection and saving energy ...... 4

4 Operating modes ..................................................... 5

5 Familiarising yourself with your appliance .......... 5

6 Before using for the first time ................................ 5

7 Basic operation ....................................................... 6

8 Cleaning and servicing .......................................... 7

9 Troubleshooting ..................................................... 8

10 Disposal ................................................................. 9

11 Customer Service ................................................. 9

12 Accessories ........................................................... 9

13 INSTALLATION INSTRUCTIONS ....................... 10

13.3 Secure installation ........................................... 10

1 Safety

Observe the following safety instructions.

1.1 General information

¡Read this instruction manual carefully.

¡Keep the instruction manual and the product

information safe for future reference or for

the next owner.

¡Do not connect the appliance if it has been

damaged in transit.

1.2 Intended use

Only use this appliance:

¡For extracting cooking vapour.

¡in private households and in enclosed

spaces in a domestic environment.

¡up to an altitude of max. 2000m above sea

level.

Do not use the appliance:

¡With an external timer.

1.3 Restriction on user group

This appliance may be used by children aged

8 or over and by people who have reduced

physical, sensory or mental abilities or inad-

equate experience and/or knowledge,

provided that they are supervised or have

been instructed on how to use the appliance

safely and have understood the resulting

dangers.

Do not let children play with the appliance.

Children must not perform cleaning or user

maintenance unless they are at least 15 years

old and are being supervised.

Keep children under the age of 8 years away

from the appliance and power cable.

1.4 Safe use

WARNING‒Risk of fire!

Fatty deposits in the grease filters may catch

fire.

Never operate the appliance without a

grease filter.

Clean the grease filters regularly.

Never work with naked flames close to the

appliance (e.g. flambéing).

Do not install the appliance near a solid fuel

heating appliance (e.g. wood- or coal-burn-

ing) unless the heating appliance has a

sealed, non-removable cover. There must be

no flying sparks.

Hot oil and fat ignites very quickly.

Always supervise hot oil and fat.

Never extinguish burning oil or fat with water.

Switch off the hotplate. Extinguish flames

carefully using a lid, fire blanket or some-

thing similar and leave to cool down.

When gas burners are in operation without any

cookware placed on them, they can build up a

lot of heat. A ventilation appliance installed

above the cooker may become damaged or

catch fire.

Only operate the gas burners with cookware

on them.

Operating multiple gas hobs at the same time

generates a great deal of heat. A ventilation

Safety en

appliance installed above the cooker may be-

come damaged or catch fire.

Only operate the gas hobs with cookware on

them.

Select the highest fan setting.

Never operate two gas hobs simultaneously

on the highest flame for longer than 15

minutes. Two gas hobs correspond to one

large burner.

Never operate large burners of more than

5kW with the highest flame for longer than

15minutes, e.g. a wok.

Fatty deposits in the grease filters may catch

fire.

Clean the grease filters regularly.

WARNING‒Risk of suffocation!

Children may put packaging material over their

heads or wrap themselves up in it and suffoc-

ate.

Keep packaging material away from chil-

dren.

Do not let children play with packaging ma-

terial.

Children may breathe in or swallow small

parts, causing them to suffocate.

Keep small parts away from children.

Do not let children play with small parts.

WARNING‒Risk of poisoning!

Risk of poisoning from flue gases being drawn

back in. Room-air-dependent heat-producing

appliances (e.g. gas, oil, wood or coal-oper-

ated heaters, continuous flow heaters or water

heaters) obtain combustion air from the room

in which they are installed and discharge the

exhaust gases into the open through an ex-

haust gas system (e.g. a chimney). With the

extractor hood switched on, air is extracted

from the kitchen and the adjacent rooms.

Without an adequate supply of air, the air pres-

sure falls below atmospheric pressure. Toxic

gases from the chimney or the extraction shaft

are sucked back into the living space.

Always ensure adequate fresh air in the

room if the appliance is being operated in

exhaust air mode at the same time as a

room-air-dependent heat-producing appli-

ance is being operated.

It is only possible to safely operate the appli-

ance if the pressure in the room in which the

heating appliance is installed does not fall

below 4Pa(0.04mbar). This can be

achieved whenever the air needed for com-

bustion is able to enter through openings

that cannot be sealed, for example in doors,

windows, incoming/exhaust air wall boxes or

by other technical means. An incoming/ex-

haust air wall box alone is not sufficient to

ensure compliance with the limit.

In any case, consult your responsible chim-

ney sweep. They are able to assess the

house's entire ventilation setup and will sug-

gest the suitable ventilation measures to

you.

Unrestricted operation is possible if the ap-

pliance is operated exclusively in circulating-

air mode.

Using a gas cooking appliance leads to a

build-up of heat, moisture and combustion

products in the room where the appliance is

installed.

Switch on the extractor hood when using a

gas cooking appliance.

WARNING‒Risk of burns!

The accessible parts of the appliance become

hot during operation.

Never touch these hot parts.

Keep children at a safe distance.

The appliance becomes hot during operation.

Allow the appliance to cool down before

cleaning.

WARNING‒Risk of injury!

Components inside the appliance may have

sharp edges.

Carefully clean the appliance interior.

Changes to the electrical or mechanical as-

sembly are dangerous and may lead to mal-

functions.

Do not make any changes to the electrical

or mechanical assembly.

The light emitted by LED lights is very dazzling,

and can damage the eyes (risk group 1).

Do not look directly into the switched-on LED

lights for longer than 100seconds.

Improper repairs are dangerous.

Repairs to the appliance should only be car-

ried out by trained specialist staff.

Product specificaties

Merk:	Bosch
Categorie:	Afzuigkap
Model:	DFS098K54
Soort bediening:	Touch
Kleur van het product:	Roestvrijstaal
Ingebouwd display:	Nee
Gewicht:	14700 g
Breedte:	898 mm
Diepte:	290 mm
Netbelasting:	196 W
Snoerlengte:	1.75 m
Geluidsniveau:	52 dB
Jaarlijks energieverbruik:	37 kWu
Soort:	Semi-inbouw (uittrekbaar)
Uitlaat aansluiting diameter:	150 mm
Illuminance:	355 Lux
Motor inbegrepen:	Ja
Materiaal behuizing:	Roestvrijstaal
Maximale afzuigcapaciteit:	412 m³/uur
Afzuigmethode:	Afvoerend/recirculerend
Fluid dynamic efficiency class:	A
Verlichtingefficiëntieklasse:	A
Vetfilterefficiëntieklasse:	B
Geluidsniveau (lage snelheid):	42 dB
Minimale afstand van electrische hob:	430 mm
Minimale afstand van gas hob:	650 mm
Aantal lampen:	3 gloeilamp(en)
Type lamp:	LED
Soort vetfilter:	Roestvrijstaal
Wasbaar filter:	Ja
Hoogte (min):	378 mm
Hoogte (max):	378 mm
Vermogen lamp:	1.5 W
Geluidsniveau (hoge snelheid:	52 dB
Maximum hercirculeringsvermogen:	392 m³/uur
Verwijderbare filter:	Ja
Installatie compartiment breedte:	524 mm
Installatie compartiment diepte:	290 mm
Installatie compartiment hoogte:	337 mm
Aantal snelheden:	5
Geluidsniveau (hercirculatie modus):	69 dB
Stroom:	10 A
Verlichtingspositie:	Rug
Automatisch uitschakelen:	Ja
Intensieve stand:	Ja
Geluidsniveau (intensieve snelheid):	75 dB
Dimbare verlichting:	Ja
Vaatwasserbestendig filter:	Ja
Land van herkomst:	Duitsland
Kleurtemperatuur:	3500 K
AC-ingangsspanning:	220 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Energie-efficiëntieschaal:	A+++ tot D
Indicator filterreiniging:	Ja
Diameter uitlaataansluiting (min):	120 mm
Boostpositie uitgangsrecirculatievermogen:	746 m³/uur
Boostpositie luchtafvoervermogen:	867 m³/uur
Bosch-technologieën (luchtafvoer):	EcoSilence Drive™ motor
