File: K:\Webshop\T-Produktbeschreibung\60\Originale_Englisch_PA04\4300282_01014.doccreate date / Erstelldatum 20.08.2004 9:37

up dated / aktualisiert: 24.08.2004

4

1

3

2

Mitre Saw

A

rt.-No.: 43.002.82

KGS 210 with second saw blade

Bar-Code: 4006825507058

Sales unit: 1 pcs

With the mitre Saw KGS 210 warrents a clean and smooth cut of wooden parts without problems. Double mitre cuts are

possible with its tilting and swivelling motor-head.

As special accessories available:

HSS-saw blade Art.-No: 45.020.42

∅

∅∅

∅∅ 210 x

∅∅

∅ 30 x 1,8 mm 72 teeth

Bar Code: 4006825456042

HM-saw blade Art.-No.: 45.020.48

∅

∅∅

∅∅ 210 x

∅∅

∅ 30 x 2,8mm 24 teeth

Bar Code: 4006825456004

Features:

-

Carbide tipped saw blade (1)

-

Rotating table (2) with precise cuts ranging (3)

from–45 ° until + 45 ° adjustable

-

Position of lock in 15 °, 22,5 °, 30 °, 45 ° 90 °

-

Tilting motor head continuously form 0 ° to + 45 °

-

Clamping device form for xation of work piece (4)

and transport locking

-

incl. second saw blade HSS – saw blade (5) ∅

∅∅

∅ 210 x

∅

∅∅

∅ 30 x 1,8 mm 72 teeth

Technical data:

- Mains: 230 V ~ 50 Hz

- Power: 1.200 Watt

- Idle speed n

o

: 4.200 min

-1

- Saw blade: Ø 210 x Ø 30 x 2,8 mm

- No. of teeth.: 24

- Turning range: 2 x 45°

- Panels max: 120 mm

- Mitre cut: 0 ° bis 45 ° to the left side

- Saw bed support: 385 x 140 mm

- Saw width max. 90 °: 120 x 60 mm

- Saw width max 45°: 84 x 60 mm

- Saw width max. 2x45°: 50 x 35 mm

- Double mitre cut

- Weight: 10,6 kg

- Packing dimension: 430 x 390 x 320 mm

5
