RX150CS QUICK REFERENCE GUIDE

www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk

RX150CS

Quick Reference Guide

Our RX150CS HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ ARC Receiver

oers market leading features and outstanding value utilising CSC technology.

The product extends HDMI, Bi-directional IR & RS-232 and is powered by the Matrix

up to lengths of 150m (4K to 100m). The RX150CS Receiver features ARC support

and Ethernet pass through when used with compatible Blustream hardware and

simultaneous analogue stereo and Optical Toslink audio breakout.

Introduction

FEATURES:

• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable

• Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR

• Supports 4K 60Hz 4:4:4 UHD video up to 100m

• Extends HDMI 1080p video up to 150m (HDBaseT™ long reach mode)

• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K

• Automatic downscaling of up to 4K 60Hz 4:4:4 video input to 1080p

• Supports ARC (Audio Return Channel) from connected display via HDMI or Optical digital inputs (when used with

compatible Blustream Transmitter / Matrix)

• Bi-directional Ethernet pass through when used with compatible Blustream Transmitter or Matrix solution.

• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission

• Bi-directional RS-232 pass-through

• Supports bi-directional IR pass-through to compatible HDBaseT™ device

• Supports PoC (Power over Cable) from Blustream Matrix or Transmitter products

• HDCP 2.2 support

ONOFF5V12V

OPT

HDMICTRLFW

PLA

HDMI

OPT IN

LRMARCRS-232IR

HDBT INETHERNETRS-232

TXRX

IR INIR OUTHDMI OUTOPT OUTL/R OUT

24V 1.25A
