AD11AU QUICK REFERENCE GUIDE
01Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk||
The Blustream AD11AU has been designed to help correct audio delays incurred when
separating audio and video signals in an AV system. The AD11AU can add a delay of up to 1
second selectable in 15 increments and has a volume adjustment of -75dB to 0dB.
Introduction
• In-line 2ch analogue audio delay with line-level volume control
• Supports 48 KHz/24 Bit sample rates
• Selectable audio delay from 50-1000ms:
- 0-500ms in steps of 50ms
- 500-1000ms in steps of 100ms
• Adjustable line level volume control from -75dB to 0dB
AD11AU
Quick Reference Guide
FEATURES:
1USB Update Port - Micro USB connector used for firmware upgrade
2L/R Analogue Audio Input – RCA L/R 2ch input
3Power LED Indicator - Lit when detecting unit is powered
4Power Port – Use supplied 5V/1A DC adaptor
5Audio Delay Rotary Dial - Rotate to adjust audio delay (see page 2 for delay settings)
6L/R Analogue Audio Output – RCA L/R 2ch output
7Volume Control Rotary Dial - Rotate to adjust volume level (‘0’ = Mute)
Panel Description
1234567
Rear PanelFront Panel
Product specificaties
| Merk: | Blustream |
| Categorie: | Niet gecategoriseerd |
| Model: | AD11AU |
| Kleur van het product: | Zwart |
| Aantal: | 1 |
| Digitale audio optische in: | 1 |
| Digitale audio-ingang (coax): | 1 |
