Advanced Control Module
ACM210
Description
Our Multicast distribution platform allows distribution of HDMI video
over a 1Gb Network switch. The ACM210 Advanced Control Module
allows for third party control of the Multicast system using TCP/IP,
RS-232 and IR.
The ACM210 includes a web interface module for control and
conguration of the Multicast system and features 'drag and drop'
source selection with video preview and independent routing of
video, audio, IR, RS-232, USB / KVM and CEC.
Major third party drivers simplify Multicast product installation
and negate the need for an understanding of complex network
infrastructures.
CONFIGURATION
Key Features
•
Web interface module for conguration and control of the
Blustream Multicast system
• Intuitive 'drag & drop' source selection with video preview feature
for active monitoring of system status
• Advanced signal management for independent routing of IR,
RS-232, USB / KVM, audio and video
• Auto system conguration
• 2 x RJ45 LAN connections to bridge existing network to Multicast
video distribution network, resulting in:
- Better system performance as network trac is separated
- No advanced network setup required
- Independent IP address per LAN connection
- Allows simplied TCP/IP control of Multicast system
• RS-232 integration for control of Multicast system
• IR integration for control of Multicast system
• PoE (Power over Ethernet) to power Blustream product from PoE
switch
• Local 12V power supply (optional) should Ethernet switch not
support PoE
• Support for iOS and Android App control
• 3rd Party drivers available for major control brands
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.
25mm
190mm
VIDEO LAN (PoE)CONTROL LANIR CTRL
IR
5V12V
LINKLINKPoE
12V 1A
RS-232NORMALRESET5V
12V
IO1
IO2
IO3
IO4
V OUT
IO LEVELMCU
ACM210
