P/N 750301 Page 1
© Copyright 2007 Prizer –Painter Stoves Works
INSTALLATION, USE AND CARE MANUAL
FOR PROFESSIONAL VENTILLATION FOR
THE HOME
MODELS: BS-PL SERIES, BS PC SERIES-
IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE MAKING
ANY CONNECTIONS.
8. TO AVOID RISK OF FIRE , ELECTRIC SHOCK, OR INJURY TO PERSONS, TURN OFF THE ELECTRICI-
TY TO THE HOOD FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING.
This product is intended for domestic use only!
P/N 750301 Page 2
TABLE OF CONTENTS
Table of Contents ................................................................................................................................... 2
Safety Instructions ............................................................................................................................... 3 4-
Introduction ............................................................................................................................................ 5
Welcome ................................................................................................................................................ 6
Handling & Unpacking .......................................................................................................................... 7
Packing list for your Vent Hood ....................................................................................................... 8 9-
......................................................................................................................... Pro Line Hoods 8
Pyramid Style Hoods ............................................................................................................... 9
Installation of Pro Line Series
Dimensions…………. .. ……………………………………………………………………10
Site Preparation …………………………………………………………………………….. 11
The Correct Height …………………………………………………………………………...12
Duct Information ……………………………………………………………………………..13
Blower Installation …………………………………………………………………………...14
Custom Duct Installation ……………………………………………………………………..15
Installation of Pyramid Style
............................................................................................................................. Dimensions 16
Site Preparation .................................................................................................................... 17
The Correct Height ................................................................................................................ 18
Duct Information ................................................................................................................... 19
Blower Installation ................................................................................................................ 20
Flue Installation ..................................................................................................................... 21
Wire Diagram ..................................................................................................................................... 22
Cleaning and Maintenance ................................................................................................................. 23
Warranty .......................................................................................................................................... 24 25-
Performance Checklist .................................................................................................................... 26 27-
P/N 750301 Page 3
IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE SERVIC-
ING OR MAKING ANY CONNECTIONS.
8. TO AVOID RISK OF FIRE , ELECTRIC SHOCK, OR INJURY TO PERSONS, TURN OFF THE ELCTRICITY
TO THE HOOD FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING.
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
ï‚· USE THIS UNIT IN THE MANNER INTENDED
BY THE MANUFACTURER, IF YOU HAVE
ANY QUESTIONS PLEASE CALL 610.374.7679
ï‚· BEFORE CLEANING OR SERVICING UNIT,
SWITCH POWER OFF TO THE UNIT AT THE
SERVICE PANEL AND LOCK OUT THE SER-
VICE PANEL. IF THE SERVICE PANEL CAN-
NOT BE LOCKED OUT, PLEASE AFIX A
WARNING DEVICE PROMINENTLY, SUCH AS
A TAG, TO THE SERVICE PANEL.
WARNING! WARNING!
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
ï‚· INSTALLATION WORK AND ELECTRICAL
WORK MUST BE PERFORMED BY QUALIFIED
INDIVIDUALS IN ACCORDANCE WITH ALL
APPLICABLE CODES AND STANDARDS, IN-
CLUDING ALL FIRE RATED CONSTRUCTION
ï‚· DO NOT DAMAGE ANY EXISTING ELECTRI-
CAL OR HIDDEN UTILITIES WHEN DRILL-
ING , CUTTING AND/OR REMOVING A WALL,
CEILING OR FLOOR
ï‚· DUCTED FANS MUST VENT OUTDOORS
ï‚· SUFFICIENT AIR IS REQUIRED TO PROPERLY
EXHAUST GASES THROUGH THE FLUE OF
NATURAL AND LIQUID PROPANE FUELED
COOKING EQUIPMENT TO AVOID ANY BACK
DRAFTING. FOLLOW ALL LOCAL AND NA-
TIONAL CODES AND STANDARDS FOR PROP-
ER AIR REQUIREMENTS.
ï‚· USE ONLY METAL DUCTWORK
ï‚· NEVER VENT DUCTED EXHAUST AIR INTO
ANOTHER ROOM OR GARAGE. TO REDUCE
THE RISK OF FIRE AND TO PROPERLY VENT
EXHAUST AIR, DUCT MUST VENT OUT-
DOORS
ï‚· MATERIAL IN THIS MANUAL IS FOR REFER-
ENCE ONLY. DUE TO CONTINUOUS IM-
PROVEMENT THE MANUAL MAY DIFFER
FROM ACTUAL PRODUCT.
WARNING!
TO REDUCE THE RISK OF A RANGETOP GREASE
FIRE:
ï‚· NEVER LEAVE THE APPLIANCE UNATTEND-
ED DURING USE. BOIL OVERS MAY OCCUR, -
CAUSING SPILLS WHICH MAY IGNITE.
ï‚· DO NOT USE WATER ON GREASE FIRES.
NEVER PICK UP A FLAMING PAN. IT IS REC-
OMMENDED YOU PURCHASE A MULTI-
PURPOSE DRY CHEMICAL OR FOAM TYPE -
FIRE EXTINGUISHER FOR YOUR HOME.
STORE IT IN CLOSE PROXIMITY TO YOUR
APPLIANCES.
TO REDUCE THE RISK OF A RANGETOP GREASE
FIRE (CONTINUED):
