INSTALLATION and
USE & CARE
WALL HOODS
Models starting with: AT, BZ, HA, IN, ME, MH, NR, PL, PM, PY, SC, WR
197299 Rev 1
1. This appliance was designed for ease of installation and operation. However, we recommend that you read all
sections of this manual before you begin installation.
2. Do not remove permanently aîxed labels, warnings or data plates from your appliance. This may void the
manufacturerâs warranty and/or hinder effective servicing and maintenance. These instructions are to remain with
the appliance and the consumer is to retain them for future reference.
3. Please observe all local and national build codes and ordinances. If no local codes are applicable, please follow all
wiring requirements in accordance with the National Electrical Code.
4. Please check your local codes for any make-up air requirements.
5. This hood is for residential use only and is not designed for installation over a commercial product.
IMPORTANT
To reduce the risk of îre, electric shock or injury observe the following:
â˘Use this unit in the manner intended by the manufacturer.
â˘Before cleaning or servicing unit, turn power oî to the unit at the service panel.
â˘Installation work and electrical work must be performed by qualiîed individuals in accordance with all applicable
codes and standards, including fire-rated construction.
â˘Do not damage any existing electrical or hidden utilities when drilling, cutting and/or removing a wall, ceiling or îoor.
â˘Suîcient air is required to properly exhaust gases through the îue of natural and liquid propane fueled cooking
equipment to avoid any backdrafts.
â˘Use only metal ductwork. Do not use îexible or corrugated duct.
â˘Never vent ducted exhaust air into another room or garage. Ducted exhaust air must vent outdoors.
WARNING
INSTALLATION INSTRUCTIONS
4
Installation of Ducting for Proper Operation:
Proper installation of ducting is extremely important for optimal performance of your ventilation system. It is a basic
requirement that the kitchen is provided with an air intake to ensure good air circulation proper operation and, therefore,
of the hood. Without this incoming air, a depression could form that would reduce the eîciency of the ventilation
system.
â˘Be sure to follow local building codes for electrical, structural, general HVAC, and make-up air requirements.
â˘If duct shape is changed along path (round to square), the cross-sectional area must not be reduced.
â˘The duct run should be kept under 30 feet for a straight run. For every 90 degree turn in the duct run, subtract 5 feet
from the total (25â for a duct run with 1 elbow, 20â for a duct run with 2 elbows, and so on). Longer runs will result in
decreased performance and possible noise concerns.
â˘Avoid sharp-angled turns. Use smooth gradual turns, such as adjustable elbows or 45-degree angled turns.
â˘Airîow must not be restricted at the end of the duct run.
â˘A backîow damper is not provided. It should be sourced locally and sized for your speciîc duct work.
â˘Duct should terminate to an outdoor space above the roof line or outside a side wall of the building. Do not
terminate the run into an attic or chimney.
INSTALLATION INSTRUCTIONS
Electrical Speciîcations:
This hood is designed to be plugged into a dedicated 3-
prong ANSI or Non-GFCI outlet 120Volt, 60Hz, 1Ph, â
10amp. min.
Outlet location: Conîrm with local building codes for
accessibility requirements. The outlet may be
positioned above the hood shell to provide access for
the cord along the duct exhaust. Ensure the outlet will
not be obstructed by the duct work. The power cord will
extend up to 36â from the top of the liner.
Depending on speciîc installation conditions,
access to the outlet may be diîcult.
If an appropriate outlet is not available or is inconvenient
due to the speciîc installation, the power cord may be
removed at the linerâs junction box, and the hood may
be direct wired to a dedicated non-GFCI 120V, 60Hz,
1Ph, 10amp min circuit. Use 14-2 MC shielded cable or
equivalent, unless directed otherwise by local building
codes.
7
3-prong cord attached
3-prong cord removed
for direct wire
To reduce the risk of îre, electric shock or injury, observe the following:
â˘Use only metal ductwork. Do not use îexible or corrugated duct.
WARNING
