GRANITE LINK AP

Portable Access Point

Instruction Manual

Rev 1.0

www.blueshape.net

Introduction

GRANITE LINK AP is a portable Access Point that generates the

default Wi-Fi network necessary to unite together, GRANITE TWO

and GRANITE MINI battery packs in a unique Wi-Fi network when

operating on the field.

It is assembled in a robust and convenient carrying case suitable for

hooking on a belt for easier transportability.

It is battery operated by internal high capacity cells allowing a long

operational runtime on the field, and if needed, can conveniently

double up as a power bank for mobile devices like smartphones or

tablets.

Description

1

Mini USB charging port: use the cable provided to charge the

internal battery from any suitable AC-DC USB adapter or from

any suitable USB power outlet

2

Reset button: use a pointed object and press for 5 seconds to

reset to factory default in case of erratic behaviour

3

USB port providing 5V-1A suitable for charging portable devices

such as Smartphones or small tablets and to be used when in

Power Bank mode

4

Battery Level indicator: press the button to display the battery

charging status.

The display also shows the actual device status:

C: Power Bank turned on

R: Wi-Fi access Point powering up

Wi-Fi: Access Point turned on and data activity present

Charging: the internal battery pack is charging

Charging complete: the battery is fully recharged

5

3-position sliding switch. From bottom to top:

O – Off

C – Power Bank: turn on the USB port

R – Router: turn off the Wi-Fi access point

Instructions

Turn the Wi-Fi on and wait approx 20sec for the “BLUESHAPE

Granite Link” network to become operative. All the GRANITE TWO

and GRANITE MINI batteries will automatically join this network when

their internal Wi-Fi module is tuned on and are not connected already

to some other preferential network.

In order to read battery data, join this network with any smartphone and tablet having the GRANITE Link App properly installed

(supported OS: iOS and Android).

We recommend you charge the internal battery before using the device.

Specifications

Wi-Fi 2.4GHz 802.11 b/g/n

SSID: BLUESHAPE Granite Link

Password: blueshape00

Internal battery: Li-Ion 3.6V 10Ah 36Wh

Cordura-Like case with Velcro straps and rotating hook

Dimensions: mm 80(w) x 120(h) x 55(d)

Weight: 270 grams

Accessories supplied

1x Portable Access Point

1x Cordura-like case

1x Mini USB charging cable

1 x Instruction manual
