Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

February2010

MT1000A-85-R4

BLACKBOX

®

Break the 16-foot (5-m) USB distance barrier.

This local transmitter/remote receiver pair extends

USB over a duplex fiber link.

IC404A extends USB over a multimode LC fiber link up to 1600 feet (500 m).

IC406A extends USB over a single-mode LC fiber link up to 6 miles (10 km).

4-Port Fiber Optic USB 2.0 Extenders Quick Start Guide

June 2010

IC404A

IC406A

Before you get started, make sure that all the drivers required for your USB device(s) are installed.

1. Place the units where you want them and connect the fiber cabling to the Link ports on the local and remote units.

IC404A or IC406A

local unit

IC404A or IC406A

remote unit

LC-LC crossover duplex cable (not included)

Maximum 500 m multimode fiber

for IC404A; maximum 10 km single-mode

fiber for IC406A
