Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

February2010

MT1000A-85-R4

BLACKBOX

®

AC model detects voltage from 50 to 250 VAC

and indicates Alarm or Normal. DC model

is user-programmable with both the base

and top voltage from 0 to 60 volts.

Voltage Sensors

EME1A1-005

EME1D1-005

Overview

The Voltage Sensors monitor the presence or absence of AC or

DC voltage. The AC model includes an Alarm/Normal indicator

in the device firmware. Use up to two AC voltage sensors per

AlertWerks

™

ServSensor Junior (EME102A), and up to eight per

ServSensor (EME108A).

Connect up to eight voltage sensors to AlertWerks V4E

(EME134A)ServSensor Expansion Hub RJ-45 sensor ports.

The voltage sensors include an SNMP interface for alarm/

normal status. Set these using the Web interface and configure

them to send alerts as SNMP traps, e-mail, and SMS (text

message).

For features, turn this page over…

Specifications

Communications Cable —RJ-45 jack to sensor using UTP

CAT5 cable

Maximum Extension Cable Length — 1000 ft. (304.8-m)

with approved low-capacitance shielded cable or UTP

Measurement Indication — EME1A1-005: Alarm or Normal

Measurement Range — EME1A1-005: Detects voltage

at 50 to 250 VAC;

EME1D1-005: User-programmable from 0 to 250 VDC

Measurement Rate — Multiple readings every second

Sensor Type — Open/closed contact switch
