Operating the product

Quick Guide

1 On/Off Key

2. Rinse Aid Indicator

3. Programme Indicators / Water Overflow Warning (P1 Flashes)

6. Delayed Start Key

7. Time Delay Countdown Indicator

8. Start / Pause / Cancel Key

9. Salt Indicator

10. Water Cut-off Indicator

Hygiene Intense function

1 2 3

4 5 6 7 8

109

Read “Safety Instructions” section first!

SelfDry Function

1 2 3 4 5 6

Auto Intensive Eco * Delicate Quick&Shine (#) Mini (#)

45-65 ºC 70 ºC 50 ºC 40 ºC 60 ºC 35 ºC

Determines the soiling

degree of the dishes and

sets the temperature and

amount of the washing

water as well as the

washing time

automatically. Suitable for

all types of dishes.

Suitable for heavily soiled

dishes, pots and pans.

Suitable for washing

dishes with normal

amount of soil. It is the

most efficient program in

terms of combined power

and water consumption.

This is used for assessing

the compliance with EU's

eco-design directive.

Special programme for

gentle cleaning of delicate

glassware.

Daily washing programme

for normally soiled dishes

in the fastest way.

Suitable for lightly soiled

daily dishes that are

scraped or pre-cleaned.

Medium to high High Medium Low Medium Low

+ + + + - -

+ + + + + +

+ + + + + -

145-193 173 240 135 58 30

10,8-14,1 15,4 9,9 13,9 10,6 10,6

0,90-1,45 1,65 0,849 1,26 1,2 0,8

Programme Data and Average Consumption Values Table

Loading Capacity: 14

EN 60436:2016 The consumption values shown in the table were determined under standard conditions. Differences may therefore occur under practical conditions. * Reference

programme for testing institutes. The tests in accordance with EN 50242/60436 must be carried out with a full water softener salt dispenser and a full rinse aid reservoir, and using the test

programme. The values given for programmes other than Eco 50°C programme are indicative only. (#) Additional functions might cause changes in programme durations.

Programme number

Programme name

Cleaning temperature

Degree of Soiling

Energy (kWh)

Prewash

Wash

Dry

Duration (min)

Water (I)

Programme Table

Adjusting the water softening system

•Unpack the test strip.

•Open the tap and let the water flow for approx. 1

minute.

•Dip in the test strip into the water for 1 second.

•Take out the strip from the water and shake it.

•Wait for 1 minute.

•Make the necessary adjustment according to the test

strip.

Level 0

Level 1

Level 2

Level 3

Level 4

Level 5

After detecting the water hardness:

1. After turning on your machine, press and hold the Delayed Start and Start/Pause/

Cancel keys respectively.

2. Using the Delayed Start key, turn on LEDs 9 and 3.

3. Use the function keys to adjust the water hardness level.

4. Press On / Off key to save the setting.

Washing, rinsing and drying performance of your dishwasher will improve when the water

softening system is adjusted correctly.

To adjust the system, first learn the water hardness in your region and adjust as indicated

below.

Quick Guide

Water hardness level adjustment table

Hardness

Level

English Water

Hardness °dE

German Water

Hardness °dH

French* Water

Hardness °dF

Water Hardness Level Indicator

Level 0

0-5 0-4 0-8

On the 1

level, the 1

programme LED turns on.

Level 1

6-9 5-7 9-13

Level 2

10-15 8-12 14-22 On the 2

level, the 2

programme LED turns on.

Level 3

16-19 13-15 23-27 On the 3

level, the 3

programme LED turns on.

Level 4

20-24 16-19 28-34 On the 4

level, the 4

programme LED turns on.

Level 5

25-62 20-50 35-90

On the 5

level, the 1

, 2

, 3

and 4

programme LEDs

turn on.

Product specificaties

Merk:	BEKO
Categorie:	Vaatwasser
Model:	BDIN16435
Apparaatplaatsing:	Volledig ingebouwd
Soort bediening:	Touch
Deurscharnieren:	Vast
Ingebouwd display:	Ja
Gewicht:	38600 g
Breedte:	598 mm
Diepte:	550 mm
Hoogte:	818 mm
Netbelasting:	2100 W
Aantal couverts:	14 couverts
Droogsysteem:	Statisch
Deurkleur:	Niet van toepassing
Uitgestelde start timer:	Ja
Startvertraging:	9 uur
Resterende tijd indicatie:	Ja
Duur cyclus:	240 min
Geluidsniveau:	45 dB
Energie-efficiëntieklasse:	D
Gewicht verpakking:	41800 g
Breedte verpakking:	644 mm
Diepte verpakking:	661 mm
Hoogte verpakking:	859 mm
Geschikt voor paneelaanpassing:	Ja
Waterconsumptie per cyclus:	9.9 l
Geluidsemissieklasse:	C
Aantal wasprogramma's:	6
Energieverbruik per 100 cycli:	85 kWu
Verstelbare voeten:	Ja
Land van herkomst:	Turkije
Diepte wanneer de deur open is:	1150 mm
Productafmeting:	Volledige grootte (60 cm)
Bestek compartiment type:	Mand
Kuip materiaal:	Roestvrijstaal
Zout indicator:	Ja
Glansmiddel indicator:	Ja
Bescherming tegen overstromen:	Ja
Half-geladen:	Ja
Afwasprogramma's:	Delicate 40°C, Eco 50°C, Express, Intensive 70°C, Quick&Shine
Energieverbruik per cyclus:	0.849 kWu
Lengte afvoerslang:	1.3 m
Bovenste mand verstelbare hoogte:	Ja
Temperatuur (max):	70 °C
Hoogte onder werkblad:	820 mm
Watertoevoer:	Koud
Bovenste korf rek:	Vouwbaar
Ingebouwde water verzachter:	Nee
Slang diameter:	16 mm
Bovenste korf instelbare hoogteniveaus:	3
AC-ingangsspanning:	220-240 V
AC-ingangsfrequentie:	50 Hz
Type beeldscherm:	LED
Energie-efficiëntieschaal:	A tot G
Zelfbalancerende scharnier:	Ja
Functie Fast+:	Ja
Verwarmingsvermogen:	1800 W
Instelbare waterontharder:	Nee
Verwijderbare bestekmand:	Ja
