·明线安装

1.按(图A)所示尺寸在安装位置钻Φ2-Φ6安装孔,并用随机附送的

胶塞塞入,用安装螺丝将挂钩紧固在上孔;

2.将后壳后面的安装卡口对准挂钩插入,按图A中,②与下孔所示的

虚线出孔位,用随机附送的螺丝将前、后壳一齐固定在墙上,然

后把螺丝胶塞塞入螺丝孔位;

3.插上电源,将电源总开关拨在“ON”位置即可。

Dispenser Components

Installation instructions

Installation tips

1.AYT-188B带有110V/220V的须刨插座，AYT-188A不带

~~

有须刨插座;

2.设有电源开关，停用时可关闭电源，可使整机不带电;

3.高、低两档热风和风量设置，随意选择;

4.手柄带有微动开关按钮，提起手柄并轻握开关按钮通电

工作，松开按钮即断电停止工作。

125mm

2

1

电源总开关

（图一）

1

2

3

4

5

6

产品特点

螺丝胶塞

Installation Instructions

Wall mounted hair dryer

挂壁式电吹风

Thanks for choosing our products , for better service , please read all the instructions before you begin.

AYT-188

-1-

www.AYTCN.com

A

1.AYT-188B is with 110V-220Vshaver socket; AYT-188A is without

shaver socket.

2.Characterizedwith a general power switch to allow this unit be power off

when it is not in using.

3.Two heatings.

4.Slightly press on the spring button to turn on and work, release that switch to

turn off.

1.Dryer Body

2.Spring button

3.Swift switch

4.Front Cover

5.Shavser Socket

6.Back Plate

1.Drill two hole of 2-6mm diameter according to the dimension shown in

picture A then insert toggle into that holes, use screw to fix its hanger to

top hole.

2.Align installation clip on the back plate to the hanger and push down, fix

front and back plate on wall with the screw, then insert toggle into screw

hole.

3.Connect with general power and move power switch to “ON”position.

·Installation with plug instructions

·Installation without plug instructions

1.As per first step of the method above.

2.Loosen the screws as per picture B to remove front cover align “open” clip

on the back plate, push down and take out the back plate and remove the

plug-connected wire from terminal.

·暗线安装

1.按（明线安装步骤1）

2.按（图B）所示先把紧固在前壳的螺丝松开,再用螺丝刀对准底板

的“Open”口,按“↓”方向一挑把底板拉出来,然后把前壳移

开，将原来带插头的电源线从接线端子除下;

General power switch

1

2

Toggle

挂壁式电吹风安装使用说明书

上孔

下孔

1

2

感谢您选用本公司的产品,为了使我们的服务让您更满意,在购买产品后请阅读安装使用说明。

Upper hole

Under hole
