Pagina 1/4
Please read the following instruction carefully before
operating your Axis Meat Grinder
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
• Plug only into grounded electrical outlets matching the nameplate
voltage.
• Do not operate unattended.
• Do not operate equipment around children.
• Do not use an extension cord with this equipment. Do not plug this
equipment into a power strip.
• Check equipment before each use to insure the equipment is clean.
• Do not wear loose fitting garments while operating this equipment.
• Use equipment in a flat, level position.
• Unplug equipment, turn off and let it cool before cleaning or moving.
• Do not spray controls or outside of equipment with liquids or
cleaning agents.
• Do not clean the equipment with steel wool.
• Keep equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate if equipment has been damaged or is malfunctioning
in any way.
UNPACKING THE EQUIPMENT AND INITIAL SETUP
1. Remove all packing material and tape, as well as any protective
plastic from the equipment.
2. Clean any glue residue left over from the plastic or tape.
WARNING
CAUTION
AX-MG12 MG22 USER MANUAL
service@mvpgroupcorp.com
sales@mvpgroupcorp.com www.mvpgroupcorp.com
AX-MG12
AX-MG22
5659 Royalmount Avenue
Montreal, Qc, Canada H4P 2P9
Tel.: 514.737.9701 / Toll Free: 888.275.4538
Fax.: 514.342.3854 / Toll Free: 877.453.8832
3560 NW 56th Street
Fort Lauderdale, FL 33309
Tel.: 786.600.4687 / Toll Free: 844.218.8477
Fax.: 786.661.4100
2
FEATURES AND CONTROLS
BEFORE FIRST USE
1. Disassemble the grinder. See “Disassembly” on page 3.
2. Wash the components. See “Cleaning” on page 4.
3. Assemble the components.
4. Attach the handle to the top of the meat grinder body.
PREPARE THE FOOD
1. For vegetables, remove stalks and stems; for meat, remove all the
skin and bones.
2. Cut the food product into appropriately-sized pieces for grinding.
OPERATION
NOTICE: Using a voltage other than the nameplate rated voltage will
cause damage to the unit. Incorrect voltage, modification
to the power cord or electrical components can damage
unit and will void the warranty.
1. Verify the grinder chamber is seated correctly on the main body.
Tighten the thumbscrew counter-clockwise until secure.
NOTICE: Hand tighten only.
2. Place the tray on the top of the grinder chamber.
3. Turn the control switch to the “FORWARD” position.
4. Use the food pusher to push the food product into grinder chamber.
Never use your fingers, hands or other objects to push food through
the grinder.
5. Feed the food into the grinder at a rate that the grinder will accept.
NOTICE: Do not force too much food product into the grinder
chamber. It can overload the grinder, causing it to stop.
6. When grinding is complete, turn the control switch to the “OFF”
position.
1
Tray. Holds the food product.
2
Faceplate. Holds the grinder plate in place.
3
Grinder Chamber. Grinds the food product and houses the
worm gear, blade, grinder plate and faceplate nut.
4
Food Pusher. To push the food into the grinder chamber.
5
Reset Button. If the grinder becomes overloaded, this button
needs to be manually reset after allowing the unit to cool.
6
Control Switch. Switches the motor between “FORWARD,”
“REVERSE” or “OFF.”
7
Funnel. Use to funnel food into the grinder chamber.
8
Main Body. Houses motor and gearbox.
9
Thumb Screw. Holds the grinder chamber to the main body.
WARNING
Entanglement Hazard
Never place fingers, hands or other objects into the feed chute
other than the food pusher provided with the appliance. Injury
and product damage will occur.
WARNING
Electrical Shock Hazard
Keep water and other liquids from entering the inside of the
equipment. Liquid inside the equipment could cause an
electrical shock.
1--------------
2----------------
3--------------------
4--------------------
---------------5
6-----------------------------
-------------------------7
---------8
--------------------9
