OPERATOR MANUAL

IMPORTANT INFORMATION, KEEP FOR OPERATOR

888-994-7636, fax 888-864-7636

uniedbrands.net

PART NUMBER PP MNL2207, REV. A (08/23)

This manual provides information for:

VENTILATION SYSTEMS

THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,

UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED

IN THIS MANUAL.

FOR YOUR SAFETY Do not store or use gasoline or other ammable vapors

and liquids in the vicinity of this or any other appliance.

NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the

consignee to inspect the container upon receipt of same and to determine

the possibility of any damage, including concealed damage. Avtec suggests

that if you are suspicious of damage to make a notation on the delivery

receipt. It will be the responsibility of the consignee to le a claim with the

carrier. We recommend that you do so at once.

Manufacture Service/Questions 888-994-7636.

RETAIN THIS MANUAL FOR FUTURE REFERENCE

NOTICE: Due to a continuous program of product improvement, Avtec reserves the

right to make changes in design and specications without prior notice.

NOTICE: Please read the entire manual carefully before installation. If certain

recommended procedures are not followed, warranty claims will be denied.

MODEL NUMBER _________________________

SERIAL NUMBER _________________________

INSTALLATION DATE ______________________

INSTALLATION INSTRUCTIONS

Avtec hoods are provided with adjustable hanging brackets designed to receive

1/2” threaded rod with a 1/2” nut and washer. Supporting rods must be

connected to all factory installed brackets. Recommended hanging height is 6’-

6” above nished oor for canopies. Low side wall ventilators should be installed

directly upon a Avtec base or on a re rated wall. If wall mounted, the bottom of

the vent should be 36” above nished oor.

ALL AVTEC VENTILATION SYSTEMS MUST BE INSTALLED IN ACCORDANCE

WITH NFPA-96, REMOVAL OF SMOKE AND GREASE-LADEN VAPORS FROM

COMMERCIAL COOKING EQUIPMENT.

BAFFLE FILTER (AF) SERIES

Model AF ventilators are listed by UL and are built in accordance of NFPA-96

for use with UL listed re extinguishing systems for duct hood protection. They

are available with or without an automatic re damper. They utilize UL classied

removable bafe lters to extract grease and provide a limited re barrier. The

canopy contains a hidden grease trough and removable cup. Surface, plenum

and duct collar re extinguishing systems may be factory supplied.

MODULAR GREASE EXTRACTORS (AX) SERIES

Model AX ventilators are listed by UL and are built in accordance of NFPA-96 for

use with UL listed re extinguishing systems for duct hood protection. They are

available with or without an automatic re damper. These models utilize high

velocity removable grease extractors. The canopy contains a hidden grease

trough and removable cup. Surface, plenum and duct collar re extinguishing

systems may be factory supplied.

FIGURE 1

FIGURE 3FIGURE 4

HOOD FACE

T-MOLDING

C-CHANNEL

FIGURE 2

INSULATED

SUPPLY DUCT

FIRE DAMPER &

VOLUME CONTROL

DAMPER

FLUID WEL

D

EXHAUST DUCT

ACCESS

PANEL

FRONT OR BACK

NOTE: HOLES DRILLED THROUGH HOOD ANGLE BY

INSTALLER AFTER BRACKET ATTACHMENT

POINTS HAVE BEEN DETERMINED.

HOOD

ANGLE

OF HOOD

HANGER BRACKET DETAIL

HANGER ROD

PRE-DRILLED

HOLE, ACCEPTS

UP TO 1/2"ÿ ROD

5/16" BOLT

HOLE, ACCEPTS

PRE-DRILLED

NUT

HANGER ROD

S.S. NUT & BOLT

BY OTHERS

Information contained in this document is known to be current and accurate at the time of printing/creation. Reference our product line website for the most updated

product information and specications. © 2023 Electrolux Professional, Inc. All Rights Reserved.
