1

AVALLON.COM

®

©2022 Ferguson Enterprises, LLC V1.0-08122022

Thank you for purchasing your panel ready undercounter wine or beverage refrigerator from Avallon. Our brand set out with one parcular

goal: To present appliances that are as reliable and recognizable as they are aainable. We create products that invite enre kitchens to be

built around them, serving as an establishing feature in the very spaces they occupy.

In accordance with our ongoing mission to provide cung-edge and forward-thinking products to our loyal customers, we recently

introduced a line of panel ready appliances. These models are fully customizable, and in just a few short steps, you can match your

undercounter refrigerator with your adjacent cabinetry.

This document serves as a guide for installing custom door panels on any of these models. For more product informaon, including owner's

manuals, dimension guides, and more, visit Avallon.com.

PRODUCT INFORMATION

PANEL INSTALLATION INSTRUCTIONS

OVERLAY PANEL INSTALLATION INSTRUCTIONS

TOOLS REQUIRED

• Phillips Screwdriver • Drill and 7/64" Drill Bit • #6 Wood Screws* • Clamps (Recommended)

IMPORTANT

Warning: The weight of the overlay panel should not exceed 15 lbs.

NOTE

*Because the sizes of overlay panels vary, hardware for mounng your overlay is not included with your Avallon panel

ready refrigerator. #6 wood screws are recommended. The required length depends on the thickness of your overlay

panel. Take care to ensure the screws are not too long to avoid them protruding though the overlay panel.

1. Open the door to a 90° angle.

2. Use a Phillips screwdriver to remove the two (2) screws from the top hinge.

3. Remove the door by carefully sliding the top of the door forward while liing the door up and out of the boom hinge assembly.
