Installation & User Guide

Auralex

®

Acoustics, Inc.

1-800-959-3343 317-842-2600 Auralex.com||

9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256

RC-8

™

Resilient Channel

1294-415.RC-8 User Guide (01/13/2020 - 10:19 AM)

Spacing and Installation :

• Secure horizontally 3” from the bottom and Wall Installation:RC-8

top of your wall, then approx. every 24” on center (Example: An 8’

high wall would require (5) 8-foot sections of per 8’ of wall RC-8

width). RC-8 is installed with the flange on bottom as shown in the

figure 1.

• Secure to ceiling joists every 12” on Ceiling Installation:RC-8

center if using multiple layers of drywall and/or . Space SheetBlok

every 16” on center if using only a single layer of drywall.

• is NOT intended or designed for floor Floor Installation:RC-8

installations. recommends using AuralexU-Boat Floor Floaters

when isolating a floor.

General Notes:

Figure 1

SheetBl

SheetBl

2” Mine

Insulatio

4” Miner

RC-8

™

Resilie

Channel

U-B

• creates a nominal 1/2” spacing between the wall stud or ceiling joist and the drywall.RC-8

• When mounting two sections of to a single wall stud or ceiling joist, overlap the pieces and secure them together with the RC-8

same screw. Do not butt the ends of the channel together, see figure 1.

• When mechanically fastening drywall to the , do not anchor the drywall to the wall stud or ceiling joist. recommends RC-8Auralex

securing the drywall at the midpoints between studs and joists to prevent accidental coupling.

• Up to two layers of ” drywall may be hung on OR one layer ” drywall, one layer of ⅝RC-8⅝Auralex SheetBlok

™

mass loaded

vinyl barrier and one layer of ½” drywall.

For best sound isolation, recommends incorporating Auralex

the following products into your room construction as shown

in figure 2:

• SheetBlok

™

Sound Barrier

• InsulationMineral Fiber

• StopGap

™

Acoustical Sealant

• U-Boat

™

Floor Floaters

Figure 2
