STREETBASS SUBWOOFERS
Features
• Composite foam surround for smooth, controlled bass
• High-precision motor assembly improves efficiency and output
• Rigid steel basket for strength and reduced resonance
• High-temperature, lightweight voice coil
• Dual dust cap design for enhanced rigidity and heat dissipation
• Non-pressed paper cone for added warmth and depth
• Large-gauge, quick-release black nickel terminals
• Show Car approved
EPIC D2 EPIC D4X12 | X12
User Guide
2
User Guide
STREETBASS SUBWOOFERS
The exclamation point within an equilateral triangle is intended to
alert the user of the presence of important operating and mainte-
nance (servicing) instructions in the literature accompanying the
appliance.
Recycling notice: If the time comes and this apparatus has fulfilled
its destiny, do not throw it out into the trash. It has to be carefully
recycled for the good of mankind, by a facility specially equipped
for the safe recycling of electronic apparatii. Please contact your
local or state recycling leaders for assistance in locating a suitable
nearby recycling facility. Or, contact us and we might be able to
repair it for you.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not submerge this apparatus in water.
6. Clean only with a dry cloth.
7. SECURE MOUNTING (trust us—it matters): Mounting your subwoofer
enclosure properly isn’t just about keeping things clean—it’s about keep-
ing things safe. A loose subwoofer enclosure can turn into an unexpected
passenger during a hard stop or sharp turn, and let’s be honest, nobody
wants to get hit in the back of the head by their own bass system. Even
more, a poorly placed or unsecured enclosure can mess with important
stuff like fuel lines, brake lines, or electrical wiring—things you definitely
don’t want to discover the hard way. So before grabbing the drill, take a
moment to check what’s behind or underneath your mounting area (call
in a pro if you're unsure).
8. Use speaker wire of sufficient size to ensure adequate current to the speaker.
For X Subwoofers, this means 10-14 gauge speaker wire.EPIC
9. To prevent excessive cone excursion and potential damage to the
subwoofer, it is advisable to use an infrasonic (subsonic) filter set half an
octave below Fb (the enclosure's tuning frequency).
10. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as the power
input terminals are damaged, objects have fallen into the apparatus, does
not operate normally, or has been dropped.
11. Exposure to high sound pressure levels may lead to permanent hearing
loss. Take every precaution to protect your hearing.
3
Specifications - EPIC D2 D4X12 /
500400 750
RMSMIN MAX
B
A
Speaker size 12 in / 300 mm .....................................................................................................
Impedance
............................................................................................EPIC D2X12 - 2 ohms
................................................................................................................... X12 - 4 ohmsEPIC D4
Voice Coil
.......................................................................................................... 2.38 in / 60 mm
Resonant Frequency
.....................................................................................................30.1 Hz
Efficiency
...........................................................................................................................86.6 dB
Magnet Dimensions
.......................................6.14 x 2.95 x 0.98 in / 156 x 75 x 25 mm
The power handling of the X12 varies depending on the enclosure the EPIC
subwoofer is installed in. Please see below to determine the enclosure type
and its power handling capabilities.
1. Sealed enclosure – 500 W RMS
2. Vented enclosure – 500 W RMS
3. Large vented enclosure – 400 W RMS
In the case of an oversized vented enclosure, reduced power is needed to control
the woofer's excursion and maintain high efficiency.
Dimensions
Overall Diameter (A)
..................................................................................12.4 in / 316 mm
Cut Out Diameter (B) ..............................................................................11.06 81 in / 2 mm
Mounting Depth (C) 6 in / 153.8 mm ....................................................................................
Mounting Height (D) 1 in / 24 mm .........................................................................................
Motor Diameter (w/Cover) (E) 6.4 in / 162 mm ...................................................................
C
E
D
Speaker Music Power
