Atlona Technologies AT-HD19SS 1x9 HDMI

™ splitter is the perfect solution for those who want to

display a single source on 9 or more displays using just cable for each single Cat5 or Cat6

display. The Atlona splitter has 8 x RJ45 (Cat5/Cat6), one for each display and 1 x HDMI

™ output

to be used for local monitoring or a loop-out for cascading multiple splitters. AT-HD19SS is

capable of HDTV resolutions up to: 1080p@130ft and 1080i@200ft.

Note: A receiver unit (balun) is required for each display and sold separately (Model: AT-HDRS or AT-

HD15SRS).

Diagram:

For shorter transmission length, AT-HD15SRS is more recommended instead of AT-HDRS.

Product specificaties

Merk:	Atlona
Categorie:	Splitter
Model:	AT-HD19SS
Gebruikershandleiding:	Ja
Ethernet LAN:	Ja
Maximum resolutie:	1920 x 1200 Pixels
Aantal Ethernet LAN (RJ-45)-poorten:	8
Volledige HD:	Ja
HDCP:	Ja
Aansluiting voor netstroomadapter:	Ja
3D:	Ja
Ondersteunde grafische resoluties:	1920 x 1200 (WUXGA)
Bandbreedte:	225 MHz
Seriële poort(en):	1
Aansluiting video:	HDMI
AC-ingangsspanning:	5 V
Ondersteundende kabel types:	Cat5e, Cat6
Hoeveelheid Video ports:	2
