Motherboard

ROG STRIX

X570-F GAMING

E15201

First Edition

May 2019

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product contains copyrighted software that is licensed under the General Public License (“GPL”),

under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software

Licenses. Such software in this product is distributed without any warranty to the extent permitted by the

applicable law. Copies of these licenses are included in this product.

Where the applicable license entitles you to the source code of such software and/or other additional data,

you may obtain it for a period of three years after our last shipment of the product, either

(1) for free by downloading it from https://www.asus.com/support/

(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location

where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.

Legal Compliance Dept.

15 Li Te Rd.,

Beitou, Taipei 112

Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the

product for which you wish to obtain the corresponding source code and your contact details so that we

can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as

the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source

Software licenses. If however you encounter any problems in obtaining the full corresponding source

code we would be much obliged if you give us a notication to the email address gpl@asus.com, stating

the product and describing the problem (please DO NOT send large attachments such as source code

archives, etc. to this email address).

Product specificaties

Merk:	Asus
Categorie:	Tas
Model:	ROG STRIX X570-F GAMING
Breedte:	305 mm
Diepte:	244 mm
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	8
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	1
HDMI versie:	2.0b
Aantal DisplayPorts:	1
Digitale audio, optische uitgang:	1
Ondersteunt Windows:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	5, 4
Processor socket:	Socket AM4
Processorfabrikant:	AMD
Maximum intern geheugen:	128 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
Snelle installatiehandleiding:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	AMD X570
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	3
DisplayPort versie:	1.2
Geheugen slots type:	DIMM
Audiochip:	SupremeFX S1220A
Meegeleverde drivers:	Ja
S/PDIF-uitgang:	Ja
Geheugen kanaal:	Dubbelkanaals
Ondersteunde opslagstationinterfaces:	SATA III
Component voor:	PC
LAN controller:	Intel® I211-AT
Soorten RAID:	0, 1,10
Aantal SATA III connectors:	8
Wake-on-LAN:	Ja
Compatibele processors:	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Wifi:	Nee
Moederbord chipset familie:	AMD
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	- MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	256 Mbit
ACPI version:	6.2
Systeem Management BIOS (SMBIOS) versie:	3.2
Ondersteuning voor parallel processing:	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	2
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
Clear CMOS jumper:	Ja
Aansluitingen voor EATX voedingen:	1
Aantal M.2 (M) slots:	2
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
USB 3.2-connectoren (3.1 Gen 2):	1
