Pagina 1/68

Industrial Motherboard

Q670EA-IM-A

E23526

Revised Edition V5

April 2024

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Product specificaties

Merk:	Asus
Categorie:	Niet gecategoriseerd
Model:	Q670EA-IM-A
Breedte:	305 mm
Diepte:	244 mm
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	3
Certificering:	CE, FCC, BSMI, VCCI, RCM\nCE-LVD
HDMI versie:	2.1
Aantal DisplayPorts:	2
Ondersteunt Windows:	Windows 10 IoT Enterprise, Windows 10 x64
Temperatuur bij opslag:	-40 - 85 °C
Processor socket:	LGA 1700
Processorfabrikant:	Intel
Maximum intern geheugen:	128 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	- kanalen
Ondersteunt Linux:	Ja
Ethernet interface type:	2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Lijningang:	Ja
Chipset moederbord:	Intel Q670E
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	5
DisplayPort versie:	1.4
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC897
RAID support:	Ja
PCI Express x4 (Gen 3.x) slots:	1
Maximum aantal HDD's per behuizing:	7
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Seriële poort(en):	1
LAN controller:	Intel I210-AT, Intel I226-LM, Intel I226-V
Soorten RAID:	0, 1,5, 10
Aantal SATA III connectors:	7
PCI-slots:	2
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Ondersteunde geheugen types:	DDR5-SDRAM
Bedrijfstemperatuur (T-T):	0 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 95 procent
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	3600,4000,4400 MHz
COM aansluitingen:	5
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
TPM connector:	Ja
Chassis intrusion aansluiting:	Ja
S/PDIF uitgang:	Ja
EPS power connector (8-pin):	Ja
Aantal M.2 (M) slots:	2
PCI Express x16 (Gen 5.x) sleuven:	2
PCI Express x4 (Gen 4.x) sleuven:	2
