Asus PRIME H570M-PLUS Handleiding

Asus Moederbord PRIME H570M-PLUS

Bekijk gratis de handleiding van Asus PRIME H570M-PLUS (36 pagina’s), behorend tot de categorie Moederbord. Deze gids werd als nuttig beoordeeld door 3 mensen en kreeg gemiddeld 4.3 sterren uit 2 reviews. Heb je een vraag over Asus PRIME H570M-PLUS of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/36

Motherboard

PRIME H570M-PLUS

E17785

First Edition

January 2021

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Product specificaties

Merk:	Asus
Categorie:	Moederbord
Model:	PRIME H570M-PLUS
Breedte:	244 mm
Diepte:	244 mm
USB-connectortype:	USB Type-A, USB Type-C
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	3
HDMI versie:	2.0
DVI-D poorten:	1
Aantal DisplayPorts:	1
Ondersteunt Windows:	Windows 10 x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	LGA 1200 (Socket H5)
Processorfabrikant:	Intel
Maximum intern geheugen:	128 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel H570
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
DisplayPort versie:	1.4
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887 / Realtek ALC897
Meegeleverde drivers:	Ja
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
PCI Express x1 (Gen 3.x) slots:	1
Ondersteunde opslagstationinterfaces:	M.2, SATA III
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Intel® I219-V
Aantal SATA III connectors:	6
Wake-on-LAN:	Ja
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium G
Aantal storage drives ondersteund:	8
Ondersteunde geheugen types:	DDR4-SDRAM
Wifi:	Nee
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400,2666,2800,2933,3200,3333,3466,3600,3733,4000,4266,4400,4600 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	192 Mbit
Ondersteuning voor parallel processing:	Niet ondersteund
COM aansluitingen:	1
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	2
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
TPM connector:	Ja
S/PDIF uitgang:	Ja
EPS power connector (8-pin):	Ja
Peripheral (Molex) power connectors (4-pin):	5
Clear CMOS jumper:	Ja
Supported processor sockets:	LGA 1200 (Socket H5)
Aantal M.2 (M) slots:	3
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
PCI Express x16 (Gen 4.x) sleuven:	1
Thunderbolt-headers:	1
