Pagina 1/180

Motherboard

P7F-C Series

P7F-C/SAS

P7F-C/4L

E5217

First Edition V1

December 2009

No part of this manual, including the products and software described in it, may be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form or by any means,

except documentation kept by the purchaser for backup purposes, without the express written permission

of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND

SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY

OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Product specificaties

Merk:	Asus
Categorie:	Moederbord
Model:	P7F-C/4L
Grafische adapter:	XGI Z9s
Type stroombron:	ATX
Aantal USB 2.0-poorten:	2
VGA (D-Sub)poort(en):	1
Aantal Ethernet LAN (RJ-45)-poorten:	4
Certificering:	FCC, CFR47 Part 15, Class B, CE, EN55022 & EN55024, C-TICK
Meegeleverde software:	ASWM2.0
Temperatuur bij opslag:	-40 - 70 °C
Processor socket:	LGA 1156 (Socket H)
Processorfabrikant:	Intel
Netwerkfuncties:	Gigabit Ethernet
Chipset moederbord:	Intel® 3420
PCI Express x16 slots:	2
PS/2 poort(en):	1
Seriële poort(en):	1
Soorten RAID:	0, 1
Maximum geheugen grafische adapter:	64 MB
PCI-slots:	4
Bedrijfstemperatuur (T-T):	10 - 35 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 90 procent
Moederbord form factor:	ATX
Aantal geheugenslots:	6
ATX Power connector (24-pin):	Ja
Aantal SATA-aansluitingen:	6
USB 2.0 aansluitingen:	3
Chassis intrusion aansluiting:	Ja
Soort aansluiting controller:	Intel® 3420
Aansluitingen voor EATX voedingen:	1
