Pagina 1/140

Motherboard

P13R-M

Series

E22497

First Edition

December 2023

No part of this manual, including the products and software described in it, may be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form or by any means,

except documentation kept by the purchaser for backup purposes, without the express written permission

of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

Product specificaties

Merk:	Asus
Categorie:	Niet gecategoriseerd
Model:	P13R-M
Gewicht:	760 g
Breedte:	244 mm
Diepte:	244 mm
Gewicht verpakking:	1300 g
Grafische adapter:	AST2600
Ethernet LAN:	Ja
VGA (D-Sub)poort(en):	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
Temperatuur bij opslag:	-40 - 70 °C
Processor socket:	LGA 1700
Processorfabrikant:	Intel
Maximum intern geheugen:	128 GB
Luchtvochtigheid bij opslag:	20 - 90 procent
Audio-uitgangskanalen:	- kanalen
Ethernet interface type:	Fast Ethernet, Gigabit Ethernet
Chipset moederbord:	Intel C262
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	3
Geheugen slots type:	DIMM
Grafische adapter-familie:	ASPEED
Geheugen kanaal:	Dubbelkanaals
Maximum aantal HDD's per behuizing:	8
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Component voor:	Server
Aantal SATA III connectors:	8
Compatibele processors:	Intel Pentium, Intel Xeon E
Ondersteunde geheugen types:	DDR5-SDRAM
Bedrijfstemperatuur (T-T):	10 - 50 °C
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	3600,4000,4400 MHz
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	1
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
EPS power connector (8-pin):	Ja
Ondersteunde geheugenmodule capaciteiten:	8GB, 16GB, 32GB
Aantal M.2 (M) slots:	1
Serial port headers:	1
USB 3.2-connectoren (3.1 Gen 2):	3
PCI Express x16 (Gen 5.x) sleuven:	1
