Asrock Z490M-ITX/ac Handleiding

Asrock Moederbord Z490M-ITX/ac

Lees hieronder de 📖 handleiding in het Nederlandse voor Asrock Z490M-ITX/ac (90 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 27 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Pagina 1/90

Version 1.1

Published January 2020

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	Z490M-ITX/ac
Breedte:	170 mm
Diepte:	170 mm
Bluetooth:	Ja
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth-versie:	4.2
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2304 Pixels
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
HDCP:	Ja
HDMI versie:	1.4
Aantal DisplayPorts:	1
Ondersteunt Windows:	Windows 10
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
ECC:	Ja
Ethernet interface type:	2.5 Gigabit Ethernet, Gigabit Ethernet
Chipset moederbord:	Intel Z490
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
DisplayPort versie:	1.4
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC1200
Meegeleverde drivers:	Ja
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
Aantal displays ondersteund:	2
Ondersteunde opslagstationinterfaces:	SATA III
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Dragon RTL8125BG, Intel I219-V
Soorten RAID:	0, 1,5, 10
OpenGL versie:	4.5
DirectX versie:	12.0
Aantal SATA III connectors:	4
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Wifi:	Ja
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	Intel
Moederbord form factor:	mini ITX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400,2666,2800,2933,3200,3600,3733,3800,3866,4000,4133,4266,4333,4400 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	1
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
WiFi-AP antenna jack:	2
12V vermogen-connector:	Ja
RGB LED-aansluitrail:	Ja
