Asrock Z390 Taichi Handleiding

Asrock Moederbord Z390 Taichi

Bekijk gratis de handleiding van Asrock Z390 Taichi (111 pagina’s), behorend tot de categorie Moederbord. Deze gids werd als nuttig beoordeeld door 39 mensen en kreeg gemiddeld 4.8 sterren uit 20 reviews. Heb je een vraag over Asrock Z390 Taichi of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/111

Version 1.0

Published July 2018

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI ®

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	Z390 Taichi
Breedte:	305 mm
Diepte:	244 mm
Bluetooth:	Ja
Wi-Fi-standaarden:	Wi-Fi 5 (802.11ac)
Bluetooth-versie:	4.2
Grafische adapter:	HD Graphics
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
Meegeleverde kabels:	SATA
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
Certificering:	FCC, CE, ErP/EuP
HDCP:	Ja
Aantal DisplayPorts:	1
Meegeleverde software:	ASRock A-Tuning, ASRock Polychrome RGB, ASRock XFast LAN
Ondersteunt Windows:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Ingebouwde grafische adapter:	Ja
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Intel® Turbo Boost Technology:	2.0
Intel® InTru™ 3D Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Audio-uitgangskanalen:	7.1 kanalen
Snelle installatiehandleiding:	Ja
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel Z390
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	3
DisplayPort versie:	1.2
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC1220
Meegeleverde drivers:	Ja
Grafische adapter-familie:	Intel
S/PDIF-uitgang:	Ja
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	3
PCI Express x1 (Gen 3.x) slots:	2
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Intel® I219-V
Soorten RAID:	0, 1,5, 10
DirectX versie:	12.0
Aantal SATA III connectors:	8
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	Intel Core i3, Intel Core i5, Intel Core i7
Ondersteunde geheugen types:	DDR4-SDRAM
Wifi:	Ja
Code geharmoniseerd systeem (HS):	84733020
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400,2666,2800,2933,3200,3600,3733,3800,3866,4000,4133,4200 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	256 Mbit
ACPI version:	6.0
Systeem Management BIOS (SMBIOS) versie:	2.7
Ondersteuning voor parallel processing:	3-Way CrossFireX, CrossFireX, NVLink, Quad-GPU CrossFireX, Quad-GPU SLI, SLI
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	6
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	CPU, FAN, Temperature, Voltage
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	4
TPM connector:	Ja
EPS power connector (8-pin):	Ja
Clear CMOS knop:	Ja
Discrete grafische ondersteuning:	Ja
Peripheral (Molex) power connectors (4-pin):	1
WiFi-AP antenna jack:	2
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	2
RGB LED-aansluitrail:	Ja
Thunderbolt-headers:	1
Inclusief hulpprogramma's:	Ja
Aantal M.2 € slots:	1
