WARNING

This unit has no user-serviceable parts inside. Opening the casing presents a risk of

electrocution and only use indoors. ASRock will not be responsible for any result of

improper use, including but not limited to, any use of the product outside of its intended

purpose or use inconsistent with the warranty terms available online.

Only use the included cables specically labeled for your PSU. Using incorrect cables

may run the risk of catastrophic failure.

Installation Procedures

1

Quick Installation Guide

Power Supply Series

Remove the power supply from its packaging.

NOTE

Use the screws provided with your case to

install the power supply into your computer.

Connect the 24-Pin ATX cable to the PSU and

the motherboard.

2

It is recommended to install the power supply

with the fan facing down.

However, if your case places the power supply

at the bottom of the case and there are no

ventilation holes available, it may be best to

install the power supply with the fan facing up

for greater efciency and reliability.

3

Connect the 4+4-Pin EPS12V cable to the

motherboard. (Optional)

If you plan on extreme overclocking and

your motherboard supports additional 8-Pin

or 4-Pin CPU power connectors, connect the

second 4+4-Pin EPS12V cable.

This is only needed for heavy overclocking or

for Dual CPU motherboards.

4

5

Connect the 12V-2X6 / PCIe cables to your

graphics card(s).

NOTE

Take extra care to fully plug-in the 12V-2X6

cable to PSU and your graphics card.

Avoid bending the 12V-2X6 cable within 35mm

of the 12V-2X6 connector.

Do not attempt to plug an 8-Pin PCIe cable into

a 6-Pin connector without rst detaching the

two extra pins.

We recommend to use one PCIe cable per

PCIe connector on your graphics card if the

card requires 2 or more PCIe connections.

6

Connect SATA power cables to all data drives

or optical drives (hard drives, solid state drives,

optical drives).

7

Connect the peripheral "PATA" 4-Pin connectors

for fans, pumps, legacy components and other

devices/adapters.

8

Connect the AC power cord to your power

supply and to the wall. Check all connections to

assure a solid connection and turn the power

switch on the power supply to the ON position

(If the iCOOL mode is set to ON, the fan will not

spin during low to medium loads) .
