Pagina 1/3

Steel Seal™ Washing machine

W6098X.S/3

Energy efficiency class: A

Style

Loading capacity: 9 kg

1800 rpm

Number of programmes: 26

Pro Wash™

Installation: Freestanding

Programs

• Basic washing programs: Quick, Mix/synthetic, Wool / Hand wash, Jeans,

Everyday wash, Time program, Easy Care, Standard cotton, Heavy

• Special washing programs: Allergy program Synthetics, SportWash, Quick

Pro, Bedding, Conditioning, Eco 40–60, Shirts, Auto, Hygiene, Dark wash,

Stain program, Allergy program Cotton, Steam refresh

• Special functions: Rinse, Drain, Spin, Drum cleaning

• Modes: Normal - No changes to the program, Green - Saves water and

energy. Program time slightly longer, Allergy mode - Adds extra water and

program time to ensure a well rinsed load, Speed mode - More water and

energy used to ensure a clean laundry in shorter time, Intensive mode -

Improved cleaning with more water and energy. Temperature is kept at high

level for longer, Night - Reduce noise by lowering movement of the drum, add

longer time to ensure a clean laundry.

Additional options

• Temperature range: Cold - 90 °C

• Spin speed setting: Adjustable

• Max spin speed: 1800 rpm

• Delayed start: 30 min to 24 hours

• Settings: Prewash, No spin, High water level, Super rinse

Construction and performance

• Door sealing: Steel Seal™ - Hygienic sealing without rubber bellow

• Quattro Construction™ – vibration-free spinning: Yes

• Outer drum: Stainless Steel

• Inner drum: Stainless Steel

• Counter weight material: Cast iron

• Counterweight: 20.1 kg

• Active Drum™ - Ensure a gentle yet effective washing cycle: Yes

• Max +/- 1 °C temperature variation: Yes

• Drum size: 60 l

• Door hinge placement: Left

• Door opening diameter: 310 mm

• Door maximum opening angle: 110 °

• Motor: Long life and quiet brushless motor

• Soaking system: Pro Wash™

Use and flexibility

• Easy Close door: Yes

• Door lock: Electronic

• Stop flap for Liquid detergent: Yes, possible to use both liquid and powder

detergent

• Automatic detergent drawer cleaning: Time remaining indicator

• Load Light™ - Illumination of the drum: Yes

• Automatic dosing system: Yes, integrated

• Dose assist: Yes

• Wifi: No

Interaction and control

• Remaining time indication: Yes

• Type of display: LCD display

• Transparent door cover/Double glass door: Transparent door cover

• Number of programmes: 26

• Create own program: Yes

• Language settings: Chinese simpified, Chinese traditional, Swedish,

Slovenian, Slovak, Russian, Polish, Norwegian, Dutch, Latvian, Lithuanian,

Japanese, Italian, Croatian, French, Finnish, Estonian, Spanish, English,

German, Danish, Czech

Design and integration

• Main colour of product: Colour of brushed stainless steel

• Easy mounting of ASKO dryer on top of the washers: Yes

• Loading type: Front load

• Adjustable feet: 10 mm

Safety and maintenance

• Waterproof bottom plate with leakage detection: Yes

• Maximized water inlet time: Yes

• Extra durable and leakage safe PEX inlet hose: Yes

• Drain system: Anti Block™ - Self-cleaning drain pump

• Overflow protection: Yes

• Emergency door opening function: Yes

• Child lock on display: Yes

• Unbalance detection - Protects the washer against harmful vibrations: Yes

• Draining capacity: 20 l/min

• Overheat protection: For motor and electronics

Technical data

• Loading capacity: 9 kg

• Plug type: Euro

• Connected load: 2200 W

• Voltage (V): 220-240 V

• Number of phases: 1

• Fuse: 10 A

• Frequency: 50 Hz

• Heater power: 2000 W

• Net weight: 88.5 kg

• Energy efficiency class: A

• Energy consumption per cycle for the Eco program 40-60 °C: 0.494 kWh

• Energy label program time: 210 min

• Noise spinning class: C

• Spinning performance class: A

• Water consumption per cycle for the Eco program 40–60 °C: 49 l

• Remaining moisture content 1/1: 43 %

• Water connection: Size 3/4" - Can be connected to hot or cold water

• Power consumption in off-mode: 0.3 W

• Consumption in standby mode: 0.3 W

• ISO 14001 certified manufacturing: Yes

Dimensions

• Width: 595 mm

• Height: 850 mm

• Depth: 585 mm

• Depth with door open: 942 mm

• Length of electrical cord: 2100 mm

• Length inlet hose: 150 cm

• Length outlet hose: 160 cm

Logistic information

• Packaging width: 640 mm

• Packaging height: 920 mm

• Packaging depth: 661 mm

• Gross weight: 91.7 kg

• Weight of packaging: 3.2 kg

• Product code: 741661

• EAN code: 3838782659393

Product specificaties

Merk:	Asko
Categorie:	Wasmachine
Model:	W6098X.S/3
Apparaatplaatsing:	Vrijstaand
Soort bediening:	Buttons, Rotary
Kleur van het product:	Roestvrijstaal
Deurscharnieren:	Links
Ingebouwd display:	Ja
Gewicht:	88500 g
Breedte:	595 mm
Diepte:	585 mm
Hoogte:	850 mm
Netbelasting:	2200 W
Type lader:	Voorbelading
Deurkleur:	Roestvrijstaal
Materiaal trommel:	Roestvrijstaal
Snoerlengte:	2.1 m
Trommelinhoud:	60 l
Uitgestelde start timer:	Ja
Startvertraging:	24 uur
Resterende tijd indicatie:	Ja
Kinderslot:	Ja
Energie-efficiëntieklasse:	A
Gewicht verpakking:	91700 g
Breedte verpakking:	640 mm
Diepte verpakking:	661 mm
Hoogte verpakking:	920 mm
Energieverbruik wassen:	0.494 kWu
Waterconsumptie per cyclus:	49 l
Centrifuge-droger klasse:	A
Geluidsniveau (wassen):	- dB
Sopschuimbewaking:	Ja
Onbalanscontrolesysteem:	Ja
Aanpasbare centrifugesnelheid:	Ja
Maximale centrifugesnelheid:	1800 RPM
Stroom:	10 A
Zelfreinigend:	Ja
Geluidsemissieklasse:	C
Geluidsniveau bij centrifugeren:	77 dB
Restvochtpercentage:	43 procent
Cyclustijd (max):	210 min
Aantal wasprogramma's:	26
Energieverbruik per 100 cycli:	49 kWu
Aan-/uitknop:	Ja
Verstelbare voeten:	Ja
Diepte wanneer de deur open is:	942 mm
Kuip materiaal:	Roestvrijstaal
Voetenverstelling:	10 mm
Doseringsassistent:	Ja
Bescherming tegen overstromen:	Ja
AquaStop-functie:	Ja
Lengte afvoerslang:	1.6 m
Lengte watertoevoerslang:	1.5 m
Instelbare temperatuur:	Ja
Stroomverbruik (in standby):	0.3 W
Kijkglas:	Ja
Watertoevoer:	Cold, Hot
Stroomverbruik (indien uit):	0.3 W
Verlichting in trommel:	Ja
Spoelen Plus functie:	Ja
Menutalen:	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, ITA, JPN, LAV, LIT, NOR, POL, RUS, SLK, SLV, SWE
Display verlichting:	Ja
Deur openingshoek:	110 °
Deurdiameter:	310 mm
Deur openen:	Opening aan zijkant
Automatisch doseersysteem:	Ja
Water Plus:	Ja
Nominale capaciteit:	9 kg
Trommel schoonmaken:	Ja
AC-ingangsspanning:	220 - 240 V
AC-ingangsfrequentie:	50 Hz
Type beeldscherm:	LCD
Energie-efficiëntieschaal:	A tot G
Type motor:	Borstelloos
Wasprogramma's:	Auto, Hygiene/anti-allergy, Intensive/outdoor, Jeans/denim, Rinse, Timed, Daily care, Blouse/shirt, Mix, Easy care, Eco, Spin, Hand, Cotton, Pre-wash, Sport, Quick, Steam
Aangepast programma:	Ja
