VIKING PRO

TACTICAL FLASHLIGHT

2 ENG USER MANUAL

6 GER BENUTZERANLEITUNG

10 FRA MANUEL D’UTILISATEUR

14 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

18 FIN KÄYTTÖOHJE

22 SWE ANVÄNDARMANUAL

26 NOR BRUKSANVISNING

30 POL INSTRUKCJA OBSŁUGI REV_00-0000

2 ENG USER MANUAL VIKING PRO REV_000000

• Special precisely calculated reflector for powerful wide LED and tem-

pered glass with anti-reflective coating create large central spot and

wide side spill at 2200 lumens brightness. Spill diameter is 20 meters

at 100 meters distance

• Powerful electronics provides constant brightness even at a tem-

perature of -40 °C and not fully charged battery

• Two types of operation: hunting and tactical. Tactical operation for

quick access to maximum brightness mode and Strobe mode

• Withstands any recoil due to improved springs and installation of the

driver inside a reinforced capsule filled with protective compound

• Standard 1 inch body is compatible with any accessories, including

original magnetic remote switch and magnetic mount for quick

one-motion attachment and removal

• Two-phase electronic button retained two levels of pressing similar to

mechanical switch, but became noiseless and 20 times more durable

• Non-flat button allows to easily switch the flashlight with a palm

Specifications

• Innovative technology allows using any standard 18650 Li-Ion bat-

teries with 10A discharge current and provides full protection against

short circuit even in case of contact between magnetic connector and

metal objects

• Solid body made from aircraft-grade aluminium, special matt anti-

abrasive finish without rough knurling

• Steel striking bezel with matt non-reflective black titanium coating,

which prevents location disclosure, is used for additional protection of

the optical system in the event of a fall and as a shock-crushing tool

• Active real-time temperature control to prevent overheating above

+58 °C and warning indication of low battery level

• Total protection from water, dirt and dust in accordance with IP68

standard — flashlight continues to work even at 25 meters depth up

to 5 hours. Withstands fallings from the 10th floor

• Robust and water resistant magnetic connector

ENG USER MANUAL

Thank you for choosing the products of Armytek.

Please read this manual carefully before using the flashlight.

Model Viking Pro (White)

LED/Optics Cree XHP50.2/Textured reflector

Brightness stabilization type FULL (constant light)

Light output 2200 lm

Peak beam intensity 20800 cd

Hotspot : Spill 11°:40°

Beam distance 288 m

Modes, light output and runtimes (measured

with 18650 Li-Ion 3500 mAh battery until the

light output drops to 10% of the initial value)

Turbo 2200 lm/1 h 33 min (940 lm after 3 min)

Main3 400 lm/5 h 13 min

Main2 150 lm/12 h 20 min

Main1 56 lm/32 h

Strobe2 2200 lm/15 Hz/3 h (940 lm after 3 min)

Strobe1 150 lm/15 Hz/23 h

Power source 1x18650 Li-Ion

Length/Body diameter/Head diameter 160 mm/25.4 mm/41 mm

Weight without/with battery 135 g/185 g

Dust, water and impact resistance IP68. Submersion at 25 m up to 5 h. Fallings from 25 m

X Light output for flashlights with Warm light is about 7% less, beam distance is about 3% less. All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are

performed using the battery included in the set. The data may vary due to environment, heat dissipation and other factors.
