Arecont Vision MegaView
TM
Installation Manual
1 | P a g e
MegaView
TM
Installation Manual
Inside the box:
A. Arecont Vision MegaView
TM
B. Pack of four (4) wood screws and four (4)
dry wall anchors
C. Security L- key
D. TMounting emplate
Image 1
Not included but needed:
#1 Phillips head screw driver
#2 Phillips head screw driver
Mounting the Camera:
1. Remove camera and hardware from the box.
N OTE : MegaView
TM
s N has two version , D
version and IR version, shown in image 2,
both versions embed motorized day night
switcher but only IR version supports an IR
LED ring.
N OTE : Table 1 shows current MegaView
TM
product configurations.
Image 2
Model
Resolution
Description
AV132 5IR
1.3MP
Day/Night with IR Illuminator
AV1325 DN
1.3MP
Day/Night
AV2825IR
HD: 1080p
Day/Night with IR Illuminator
AV2825 DN
HD: 1 080p
Day/Night
Table 1
D
A
C
B
IR version
DN version
Arecont Vision MegaView
TM
Installation Manual
2 | P a g e
2. Using the Mounting Template, prepare the
mounting provisions for camera installation.
3. -Use security L key to adjust MegaView
TM
bracket to appropriate position. ( Image 3 )
CAUTION: the s with Only adjust screw an
arrow pointing to them on the bracket base
and camera body ( ) Image 4
NOTE : Bracket screws are all security
screws that are tamper proof and vandal
resistant.
NOTE Bracket with : 3 axes enables easy
installation in any location, including 360°
camera body rotation, 90° tilt, 360° bracket
rotation. (image 5)
4. Align the holes in the camera with the
prepared holes on the mounting surface.
Attach the camera to the mounting surface
with the wood screws or any other hardware
that fits the mounting application. (image 6)
Image 5
Image 3
Image 4
Image 6
Adjustable Screws
Arrow
90
°
360
°
360
°
