2 Port HDMI 2.0

Distribution Amplifier

HDM2.0-1x2-II

USER MANUAL

Overview

HDM2.0-1x2-II is a high-performanceHDMI distribution amplifier. It provides high quality

audio and video outputup to UHD/4K@60Hz resolution and supports patent pending

IDOT™ EDIDmanagement. The IDOT™ EDID management will dynamically read the EDID

of each display that is connected to the outputs of the HDM2.0-1x2 and automatically

perform down scaling, chroma sampling and color depth adjustments.

Package Contents

1 x HDM2.0-1x2-II

1 x User manual

1 x Power adapter DC12V with lock

Features

Supports resolution up to 4Kx2K@60Hz (4:4:4)

Supports pixel clocks up to 600 MHz

Supports HDR

HDCP 1.4/2.2 compliant

Supports 3D pass-through

Supports EDID mode selection

Supports Daisy chain(cascading)

Specifications

FunctionHDM2.0-1x2-II

HDMI Input

1

HDMI Output

2

Micro USB

1

DIP Switch

EDID Mode Selection

Max Resolution

4Kx2K@6-Hz (4:4:4 8bit, 4:2:0 12bit)

HDCP Compliance

HDCP 1.4/2/2

Audio Support

LPCM, Dolby True HD, Dolby Digital/Plus/EX, DTS,

DTS-HD

Cable Reach

10m

Power Supply

12/1A DC

Operating Temperature

0° to 40°C

Storage Temperature

-20° to 60°C

Humidity

0 - 80% RH, Non-Condensing

Weight

295g

Dimensions (LxWxH)

124x83x25mm
