TECHNOLOGY FURNITURE

®

36” Wide AdjustaCart

Assembly Instructions

Anthro

®

Corporation Technology Furniture

®

10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com

SAVE THESE INSTRUCTIONS!

Rev. D December 2014

1-800-325-3841

02

04

03

06

10

01

05

11

09

12

07

15

08

13

14

Hello! Thank you for choosing Anthro.

Before beginning assembly of your

36” Wide AdjustaCart, please take a

moment to review the parts listed below

to verify that your shipment is complete.

Component list for part # AJ36xx/xx

01–36” W Base Tube ................Qty. 1 ...............125-5003-xx

02– Caster Insert Screws ........Qty. 4 ............325-5052-00

03– 1.75” Large End Caps .......Qty. 2 ...............175-5021-xx

04– Base Tube Screws .................Qty. 3 ..............325-5000-00

05– 26.875” Vertical Legs ..........Qty. 3 ...............125-5049-xx

06– Self-threading Screws ..........Qty. 6 ..............325-5010-00

07– Wood Screws...................Qty. 28 ..........325-5106-00

08– 36” W Recessed Shelf .......Qty. 1 .............100-6047-xx

09– Shelf Supports ......................Qty. 6 ...............175-5060-xx

10– Shelf Clamps .........................Qty. 6 ..........175-5059-xx

11– Clamp Screws .......................Qty. 6 ..............325-5086-00

12– 1.5” Small End Caps ..........Qty. 3 ...............175-5020-xx

13– 36” W Adjusta Shelf ............Qty. 1 ..........100-6167-xx

14– 36” W Caddy Shelf ..............Qty. 1 ..........100-6165-xx

15– 36” W Adjusta Mechanism .Qty. 1 ..............225-5317-00

(The Adjusta Mechanism is packaged separately & requires assembly)

The following Tools have been provided (but not shown above):

Hex Driver

5

/

32

” .........................Qty. 1 ..............375-5000-00

Hex Driver Bit

5

/

32

” ..................Qty. 1 ..............375-5003-00

(The Hex Driver Bit can be used in your electric drill)

Hex Key

5

/

32

” ..............................Qty. 1 ..................375-5016-00

8 oz. Rubber Mallet ..................Qty. 1 ..................375-5022-00

3-Way Wrench ..........................Qty. 1 ..................225-5196-03

All Screw quantities listed here are the minimum needed for your Cart

assembly. There may be a few extra Screws included, which are not

counted in the Parts List.

Anthro Corporation

®

| 10450 SW Manhasset Dr. | Tualatin, OR 97062

Toll-free: 800.325.3841 | Fax: 800.325.0045 | email: [email protected] | anthro.com

Outside the U.S. | Tel: 503.691.2556 | Fax: 503.691.2409

*300-5052-00*

300-5052-00

Warranty:

This 36” Wide AdjustaCart has a Lifetime Warranty against manufacturing defects.
