Architectural Specifications

Issued: April 2018

Page 1 of 2

WALK-IN SPECIFICATIONS

General

Walk-in coolers and freezers shall be prefabricated of modular design and construction. They shall be

designed and constructed to allow fast and easy field assembly, disassembly and enlargement by the

addition of panels.

Panel Fabrication

Standard wall, ceiling and floor panels shall be fabricated in 47” and 23” in width and shall be

interchangeable with like panels. Partition and other panels placement shall be within 1/2”

increments to meet job site conditions.

Available standard height with floor panels: 6’-6”, 7’-7”, 8’-7” . Available standard height without

floor panels with NSF vinyl screed: 6’-2”, 7’-2”, 8’-2”. Panels shall consist of Extruded Polystyrene

(XPS) rigid foam insulation, bonded permanently to interior and exterior metal “skin”. Tongue and

groove edges of panels shall be of the same panel core insulation with non-corrosive thermoplastic

cam-action panel fastener. NSF approved compression gasket shall be applied to the tongue side of all

panels on both interior and exterior.

Floor Construction

Floor panels: Shall be fabricated similar to other panels and shall be designed to withstand uniformly

distributed load of 700 lbs per square foot, suitable for foot traffic. 1,300 lbs per square foot suitable

for light rolling cart traffic. The ULTIMATE with load bearing capacity of 2,750 lbs per square foot,

suitable for hand pallet jack application.

Floorless: Provided with NSF vinyl screeds. Screed will be coved with 1/2” radius, designed to sit flat

on a finished tile/concrete floor. Screed shall be lag fastener to floor.

Insulation

Insulation shall be 4” thick, rigid Extruded Polystyrene (XPS) foam closed cell, void free, hydrophobic

or high resistance to water abortion as tested in accordance to ASTM C272 classified to UL 723 (ASTM

E84). Core material has a flame spread of 15 or less and a smoke developed of 165 or less. Self

ignition temperature of 896 degree Fahrenheit and flash ignition temperature of 734 degree

Fahrenheit as tested in accordance with ASTM D 1929. Standard with a 50 year R-value warranty.

Thermal resistance: For Coolers R-25 minimum (reported at 55 F mean temperature). For freezer R-

32 minimum (reported at 20 F mean temperature). Floor R-30 minimum.
