- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2016
Thank you for selecting American Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
M965728 Rev.1.1 (7/16)
TOWNSEND
®
2 HANDLE THERMO MIXING
VALVE TRIM
INSTALLATION
INSTRUCTIONS
T353.740
Certied to comply with ANSI A112.18.1M
RECOMMENDED TOOLS
ROUGHING-IN DIMENSIONS
Phillips Screwdriver
Flat Blade Screwdriver
7-3/8"
(186 mm)
2" TO 2-5/8"
(48 TO 68 mm)
NOTE: FITTING
MUST BE INSTALLED
WITH VOLUME CONTROL
ON TOP.
R520
1/2" NPT INLETS
or
R540
3/4" NPT INLETS
1"
(25 mm)
FINISHED
WALL
9 -5/16"
(237 mm)
7-7/16"
(189 mm)
1-7/16"
(50 mm)
3"
(73 mm)
3-11/16"
(94 mm)
6-3/4"
(173 mm)
CARE INSTRUCTIONS:
• To keep your new faucet looking new, please follow
these simple care instructions:
DO: – Simply rinse the faucet clean with clear water.
– Dry the faucet with a soft cotton cloth.
DO NOT:
– Do not use any abrasive cleaners, cloths,
or paper towels.
– Do not use any cleaning agents containing
acids, polish abrasives, or harsh cleaners
or soaps.
• Regular and routine cleaning will reduce the need for
heavy cleaning and polishing. If heavy cleaning is
required, the following procedures are recommended:
• Remove as much surface dirt and lm using clear
water and soft cotton cloth (as described above).
– Use any of the following to remove tough surface
lm and build-up:
– Mild liquid detergents
– Clear ammonia free liquid glass cleaners
– Non-acidic, non-abrasive gentle liquid or fully dissolved
powder cleansers mixed according to manufacturers
directions
– Non-abrasive liquid polishers
• Once clean, rinse faucet again with clear water to
thoroughly remove cleaner or polish and blot dry with
a soft cotton cloth.
Failure to follow these care instructions may damage
the Faucet’s finish.
Product specificaties
| Merk: | American Standard |
| Categorie: | Douchesysteem |
| Model: | Townsend T353740.002 |
