SAVE FOR FUTURE USE
7302354-100 Rev. A 4/18
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed
properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be
sure your installation conforms to local codes.
Water Supply Line
EZ-INSTALL KIT INCLUDED WITH TANK
4216.228 LEFT HAND TANK / 4216.823 RIGHT HAND TANK
BOWL 3271.101 RIGHT HEIGHT
®
ELONGATED
SOLD SEPARATELY
EZ-INSTALL KIT INCLUDED WITH BOWL
TOWN SQUARE
®
S
1.28 gpf / 4.8 Lpf 2-piece Toilet
Wax Ring
T-Bolts with
Retainer (2)
Bowl-To-Floor
Knobs (2)
Tank To Bowl
Gasket
Metallic (Brass)
Tank Nuts (2)
Plastic
Coupling Nut (1)
Coupling
Washer (1)
Attachment
Handle
Bolt Caps (2)
Toilet Seat
BEFORE INSTALLING YOUR TOILET: please see your product spec page to verify the dimensions and water supply connections.
Visit our website where you can search by Model number for the product spec page at: http://www.americanstandard-us.com/
