BATH AND SHOWER TRIM KIT
M965054 REV.1.2 (3/15)
To assure proper positioning in relation to wall,
note roughing-in dimensions.
ROUGHING-IN DIMENSIONS
Certified to comply with ANSI A112.18.1
Installation
Instructions
T430.507
T430.508
T431.507
T431.508
THREADED INLETS (STOPS)
INLETS
1/2" NPT
(13mm)
5-7/8"
(149mm)
INLETS 1/2" NPT (13mm}
OUTLETS
1/2" NPT
(13mm)
OUTLETS
1/2" NPT
(13mm)
3-3/8"
(86mm)
3-3/8"
(86mm)
3-3/8"
(86mm)
THREADED INLETS
Recommened Tools
Flat Blade Screwdriver
Adjustable Wrench
Channel Locks
Plumbers' Putty or Caulking
Phillips Screwdriver
4" (102mm)
BOTTOM OF TUB
74" FOR HEAD
CLEARANCE
(1880mm)
18" OPTIONAL
(457mm)
1/2" COPPER
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 80''
(1651 and 2032mm)'
TOP OF TUB RIM
Teflon Tape
SHR. 1/2" NOM.(13mm)
COPPER SWEAT
TUB 1/2" NOM. (13mm)
COPPER SWEAT
4-1/16"
(103mm)
5-7/8"
(149mm)
INLETS
4-1/16"
(103mm)
4-1/16"
(103mm)
INLETS
1/2" NOM.
(13mm)
COPPER
SWEAT
SHR. 1/2" NOM.
(13mm)
COPPER SWEAT
TUB 1/2"
(13mm) NOM.
COPPER SWEAT
2"
SWEAT
INLETS
SWEAT
INLETS (STOPS)
INLETS
1/2" NOM.
(13mm)
COPPER
SWEAT
FINISHED WALL
Thank you for selecting American-Standard...the benchmark
of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
BERWICK
®
/ BOULEVARD
®
1/2" NPT
(13mm)
1-5/8" to 3-1/4"
(41 to 83 mm)
1-5/8" to 3-1/4"
(41 to 83 mm)
5-5/8" REF.
(143mm)
8-1/8" REF.
(206mm)
2-3/8" D.
(60mm)
4-7/8" REF.
(124mm)
7-1/4"
(184mm)
1-3/4
"
(44 mm)
