User Instructions
Saga II™ Introduction
© ®American DJ Supply - www.americandj.com - Saga II™ Instruction Manual Page 2
Unpacking:
Thank you for purchasing the Saga II™ by American DJ . Every Saga ®
II™ has been thoroughly tested and has been shipped in perfect oper-
ating condition. Carefully check the shipping carton for damage that
may have occurred during shipping. If the carton appears to be dam-
aged, carefully inspect your unit for any damage and be sure all equip-
ment necessary to operate the system has arrived intact. In the event
damage has been found or parts are missing, please contact our toll
free customer support number for further instructions. Please do not
return the unit to your dealer without first contacting customer sup-
port.
Customer Support:
American DJ provides a toll free customer support line, to provide set ®
up help and to answer any question should you encounter problems
during your set up or initial operation. You may also visit us on the web
at www.americandj.com for any comments or suggestions. For service
related issue please contact American DJ . Service Hours are Monday ®
through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war
-
ranty. In the unlikely event your unit may require service please contact
American DJ.
PLEASE recycle the shipping carton whenever possible.
11/04
American DJ®
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
© ®American DJ Supply - www.americandj.com - Saga II™ Instruction Manual Page 4
© ®American DJ Supply - www.americandj.com - Saga II™ Instruction Manual Page 3
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Saga II™ General Instructions
Saga II™ Safety Precautions
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electri-
cal shock and fire in case of an internal short.
• Do not remove the unit cover under any conditions. There are no
user serviceable parts inside.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• To reduce the risk of electrical shock or fire, do not expose this unit
rain or moisture.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
fixture.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer.
• The fixture should be serviced by qualified service personnel
when:
A. The power cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a
m arked change in performance.
Saga II™ Operation
Power Supply:
Before plugging your unit in, be sure the source voltage in your
area matches the required voltage for your American DJ
® Saga II.™
The American DJ
® Saga II
™
is available in a 120v and 220v version.
Because line voltage may vary from venue to venue, be sure to plug
your fixture into a wall outlet with a matching power supply before
attempting to operate.
General Operation:
This fixture is designed to operate as a stand alone unit, there is no
need of a controller. The Saga II™ is ready to be plugged in, out of
the box. If there is no lamp output check the breaker and bulb. If the
breaker and bulb are good, please contact our toll free customer sup
-
port number for further instructions. Please do not return the unit to
your dealer without first contacting customer support.
Mode Switches:
The Sage come with two mode switches on the rear of the unit.
Switch 1 controls the reflector dish, switch 2 controls the gobo wheel.
When the switches are in the up position (“I”) the wheels will rotate
in
a continuous rotation regardless of sound. When the switches are in
the middle position (“0”) the wheels will remain static (no rotation).
When the switches are in the down position (“II”) the wheels will react
to sound. Each wheel may be operated separately, so one wheel may
be controlled by sound while the other may be in a rotating in con
-
tinuous motion.
Saga II™ Warranty Registration
The Saga II™ carries a one year (365 days) limited warranty. Please
fill out the enclosed warranty card to validate your purchase. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.)
number. The
R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. num
-
ber must also be written down on a piece of paper and included in
the shipping container. If the unit is under warranty, you must provide
a copy of your proof of purchase invoice. You may obtain a R.A. num-
ber by contacting customer support at (800) 322-6337.
© ®American DJ Supply - www.americandj.com - Saga II™ Instruction Manual Page 5
Fixture Cleaning:
Due to fog residue, smoke, and dust cleaning the fixture should be
carried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing every 20 days.
2. Use a small brush and normal glass cleaner with a soft cloth to
wipe down the inside casing every 30-60 days.
3. Always be sure to dry all parts completely before plugging the
unit back in.
4. Frequent cleaning will extend lamp life and ensure fixture reliability.
Cleaning frequency depends on the environment in which the fixture
operates (I.e. smoke, fog residue, dust, dew). In heavy use we rec
-
ommend cleaning on a monthly basis. Periodic cleaning will ensure
longevity, and crisp beam output.
Saga II™ Cleaning
© ®American DJ Supply - www.americandj.com - Saga II™ Instruction Manual Page 6
Trouble Shooting:
Listed below are a few common problems and solutions you should
try before contacting customer support.
Unit internal wheels rotate with no light output from the unit;
1. Be sure you have connected your unit into a matching wall outlet.
2. Remove the lamp cover and be sure the lamp is seated in its
socket properly. Occasionally lamps become loose during ship-
ping be sure the lamp is push in to its socket all the way.
3. Be sure the lamp is good.
4. If the lamps was recently replaced, be sure the lamp probes are
properly inserted in the socket assemble.
Unit does not rotate and lamp does not turn on;
1. Be sure you have connected your unit into a matching wall outlet.
2. Be sure the breaker has not blown. The breaker is located on the
back of the unit.
3. Be sure the power cord is properly seated in the power outlet.
4. Be sure your main power outlet has power.
Saga II™ Trouble Shooting
Saga II™ Breaker Reset & Lamp Replacement
Caution: Always replace with the exact same type lamp and fuse,
unless otherwise specified by an authorized American DJ
® techni-
cian. Replace with anything other than the specified part can damage
your unit and will void your manufactures warranty.
Warning: If after you have replaced the lamp or reset the breaker
and you continue to blow either one, STOP using the unit. Contact
customer support for further instructions, you may have to return the
unit for servicing. Continuing to use the unit may cause serious dam
-
age.
Breaker Reset:
This unit is equipped with a built-in safety breaker. This breaker is
designed to close the power circuit in the event of an internal short
or power surge. This will reduce the risk of electrical shock or fire and
protect the circuitry. To reset the breaker, push the breaker button in
until you hear it “pop” back in to place. If the breaker continues to
pop, stop using the unit and contact our customer support team, the
unit may need to be returned for service.g and turn it in clockwise
direction to lock the holder back in to place.
Lamp Replacement:
Caution! Never attempt to change the lamp while the fixture is
plugged in and running. Always disconnect main power and allow the
unit ample time to cool before attempting to replace the lamp.
1. Be sure to follow all the proper handling procedures included
with your new halogen lamp. Never touch the new lamp with
your bare fingers.
2. Remove the two phillips screws located on the face of the unit
and remove the socket assembly cover to expose the lamp.
3. Remove and replace the lamp.
4. Reassemble in reverse order.
This fixture is fitted with halogen lamps which are
highly susceptible to damage if improperly han
-
dled. Never touch the lamps with your bare fingers
as the oil from your hands will shorten lamp life.
Also, never move the fixture until the lamps have
had ample time to cool. Remember, lamps are not
covered under warranty conditions.
