Page 1
Ambient Weather
6845 W. Frye Road
Chandler, AZ 85226
TEL 480-346-3380 FAX 480-346-3381
www.AmbientWeather.com
EZ-30-12 Weather Station Stable Gable Mounting Kit with Mast
The EZ-30-12 mounting pole kit provides a
stable weather station mounting solution, ideal
for mounting to a vertical wall, chimney, eve, or
fence post.
Ambient Weather pole mounting kit constructed
of rust proof 10-steel tubing, galvanized using
the Flo-Coat (zinc-chromate polymer) for
excellent corrosion proof protection.
Mounting hardware includes two horizontal
mounting brackets and a support brace.
Pole is made of three assemblable 14" x 1.25"-
diameter masts. Add a mast extension (see
below) to extend the pole an additional 35".
Array pictured is not included.
Figure 1
Components
The EZ-30-12 Stable Gable Mounting Kit includes the following components:
1.Qty 4: 12” Mounting Assemblies
(these will be assembled into two
brackets in Step 1)
2.Qty 1: Support Brace
3.Qty 5: Lag Screws
4.Qty 9: 7/16” Nuts
5.Qty 9: Bolts
6.Qty 9: Lock Washers
7.Qty 3: Assemblable 14” x 1.25”
Masts
Tools and Materials Needed
7/16” deep socket or wrench
Level or Plumb
Electric drill with flat head screw tip
