FULLY AUTOMATIC WASHING MACHINE
Operation Manual
It is most important that this instruction book should be retained with the
appliance for future reference. Should the appliance be sold or transferred
to another owner, or should you move house and leave the appliance, always
ensure the book is supplied with the appliance in order that the new owner
can get to know the functioning of the appliance and the relevant warnings.
These warnings have been provided in the interest of safety. You must read
them carefully before installing or using the appliance.
ATL1010W
10.0kg
S f tpeci ica ion
Bef e using or
Parts name.......................................
1
2
Cautions...........................................
Installation and adjustment................. 4
5
6
7
8
9
10
12
14
16
17
How to u se drain hose..........................
Water inlet installation.......................
O t n pera io
Preparation before operation ..............
Load
clothes...................................
U of t n se de erge t...............................
Control panel instructions..................
Program............................. .... ....... .. .
13
Maintenance....................................
Other functions.................................
S f t .. peci ica ion..................................
Con ent ts
Troubleshooting................................
Others
17
220-240V~ 50Hz
Rated voltage and
frequency
Rated capacity of wash
and spin
Water level/water volume
( )about
Inlet pressure
ATL1010WModel
Rated input power
Weight
Product Dimensions
Wash 400W spin 340W： ：
0.05MPa-0.85MPa
10.0kg
10/97L 9/85L 8/76L 7/67L
6/59L 5/53L 4/47L 3/41L
2/36L 1/31L
About 52.5kg
W665mm D675mm H1060mm
Other functions Parts name
Before using
Pay special attention to the warning symbols. There
may be serious risks to personal body safety or
damages to the washing machine if not follow.
Please stop doing the contents with this symbol,
otherwise it will damage the appliance or injure your
personal body.
Warning symbols
Forbidden symbols
Symbol definition
1
16
The end connect to
the appliance
Bottom cover
(1pc)
Water inlet hose (2pc)
Outfall stopper
(1pcs)
Top lid
Hot Water inlet valve
Cold Water inlet valve
Power cord
Back cover
Foot wheel(2pcs)
Fixing foot(2pcs)
Drain Hose
Top frame
Detergent box
Lint filter
Control panel
Inner tub
Pulsator
balancing
apparatus
Body
Base
Adjustable foot
Accessories
The end connect to
water inlet hose connector
1.
Abnormal display
E1
E3
E2
F1
F2
E4
E0
Display Explanation
Troubleshooting
The top lid is opened
when preset is started
Close the top lid and clear the alarm
The top lid open when
spinning
Close the top lid an d clear the ala rm
Spin is not balanced
Open the top lid, place the clothes
equally, then close it and clear the alarm
After inflow of water for 40
minute, it still does not
reach to the water level set
Water Level sensor is
abnormal
inverter signal
communication wrong
Cut off the power supply and contact an
Authorised Service Agent to assist
E5
child-lock light flashing
The top lid is opened
after setting child-lock
Close the top lid and clear the alarm
After draining for 7 minutes,
it still does not reach to the
minimum of water level
During spinning, if the clothes are not placed equally in the tub, it would cause violent vibration.
This machine has imbalance adjustment function, and the vibration testing system will supervise
the running. Once vibration is beyond certain level, the adjustment system will start automatically
to adjust the imbalance.
2.Imbalance adjustment
3.Power supply is cut off automatically
a) If you did not start the program in 10 minutes after pressing the power supply button, the power
supply will be cut off automatically.
b) After the washing is finished, alarm buzzes and the power supply will cut off automatically.
4.Child lock function
a) When child lock function is set, all the buttons will be locked including POWER. If the top lid is
opened during the washing machine working, the washing will be stopped and give an alarm. But
if you can close the top lid in 5 seconds, the alarm will stop and the washing machine will continue
working. If cannot close the top lid in 5 seconds, the washing machine will begin draining if there is
water in the inner tub, even closing the top lid is not valid. During the draining, alarm will buzz every
10 seconds, when the water in the inner tub is about 5cm higher, alarm will buzz every 10 minutes.
When the draining is finished, the washing machine will be in the state of waiting, if close the top lid,
the washing machine is unlocked and start working as previous setting.
b) Once child lock is set, if top lid is opened over 5 seconds during washing or rinse(there is water in
the inner tub), washing machine will drain and alarm will buzz. If you unlock the function during
draining, the washing machine will add water to water level set and continue working.
5.Water recycle function
6.Inverter washing function
When water recycle function is set, after the last rinse finished, the washing machine will not drain
and spin.SPIN and WATER RECYCLE indicator light will be flashing and alarm will be given,the
washing machine will stop working (if nobody operate, the alarm will be given every 10 minutes,
in 1 hour, power supply will be cut off automatically). When press START/PAUSE, WATER RECYCLE
indicator light is on and the washing machine begin to drain and spin, the user can reuse the water.
Direct Drive motor is used on this machine. At the beginning of start, If you want to choose a different
washing speed and spinning speed on the initial state, pressing"WATER LEVEL" button and press
" PRESET/AIR DRY/SPEED" button, choose inverter wash and inverter spin (This function is only
applicable to "COTTON" and "HEAVY" program). And then press " PRESET/AIR DRY/SPEED"
button, choose different washing speed and spinning speed to suit different clothes and achieve better
washing and spinning
Please refer to Page 14 &15 for
troubleshooting
Please refer to Page 14 &15 for
troubleshooting
