CC-7/CC-10
Getting Started Guide
CC-7 and CC-10 are touch panels for desktop or wall mount use, configured to
run the Allen & Heath Custom Control app in kiosk mode.
Check content
Check that you received the following:
• Touch panel CC-7 or CC-10
• 12V power supply unit
• Safety sheet
Installation
CC-7 and CC-10 have threaded inserts for standard VESA 75x75mm mounting.
Allen & Heath can provide a desktop stand (part number CC-STN) and a
wall/glass mount bracket (part number CC-BRK).
Overview
CC-10
1
2
3
4
CC-7, CC-10 Getting Started Guide
AP12698 Issue 3
CC-7
1. Power button
Short press for sleep / wake up.
Long press to power down / reboot. A confirmation dialog
box is displayed on the screen.
2. DC Input and LED indicator
12V/2A DC input. Alternatively, the unit can be powered over
Ethernet.
Only use the PSU supplied with the touch panel.
The LED indicator lights up green when the unit is powered
and red when the unit is in sleep mode.
3. USB-A port
USB 2.0 port for Custom Control updates.
4. Ethernet port
PoE enabled, Gigabit Ethernet RJ45 port for connection to
the mixing system.
Operation
The touch panels are configured to launch the Custom Control app at power up
and in kiosk mode, hiding the OS status / notification bar and navigation bar,
and preventing end users from exiting the app, thus securing the settings and
operation of the touch panel.
At power up, wait until the Custom Control login screen is displayed. Select a
system from the list or enter the target IP address, enter the Username and
Password, and touch Connect.
Swipe right from the left border to access further app settings such as Auto
Login.
1
3
4
2
