Alcatel-Lucent AP1251 Handleiding

Alcatel-Lucent Access point AP1251

Bekijk gratis de handleiding van Alcatel-Lucent AP1251 (120 pagina’s), behorend tot de categorie Access point. Deze gids werd als nuttig beoordeeld door 8 mensen en kreeg gemiddeld 4.8 sterren uit 4.5 reviews. Heb je een vraag over Alcatel-Lucent AP1251 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/120

Alcatel-Lucent Enterprise

OmniAccess Stellar AP User Guide - AWOS 4.0.1

January 2021

033517-10 Rev.C

The Alcatel-Lucent name and logo are trademarks of Nokia used under license by ALE. To view

other trademarks used by affiliated companies of ALE Holding, visit: www.al-

enterprise.com/en/legal/trademarks-copyright. All other trademarks are the property of their

respective owners. The information presented is subject to change without notice. Neither ALE

Holding nor any of its affiliates assumes any responsibility for inaccuracies contained herein.

How to Use This Manual
Stellar AP User Guide
ALCATEL-LUCENT ENTERPRISE      2
Contents

1  How to Use This Manual ............................................................................................. 7
Access Stellar AP Through the GUI .................................................................................... 7
Document Conventions .................................................................................................. 7
2  Configuration Sample ................................................................................................ 8
Scenario 1: AP Group Without ALE OXO server ...................................................................... 8
Scenario 2: AP Group With ALE OXO Server (ZTP) ................................................................. 10
3  Connecting AP Group via Web Browser ......................................................................... 12
Prerequisites for Setting up and Accessing AP Group .............................................................. 12
Connect to Pre-defined SSID and Browse URL ...................................................................... 12
Using the Initializing Wizard .......................................................................................... 13
Connecting to the AP Group via Web ................................................................................ 16
PVM/SVM Election and AP Group Scalability ........................................................................ 16
4  Introduction to the AP Group Web Management System .................................................... 18
Dashboard Overview .................................................................................................... 18
WLAN Window ........................................................................................................ 18
AP Window ............................................................................................................ 20
Client Window ........................................................................................................ 23
Monitoring Window .................................................................................................. 25
System Page ............................................................................................................. 28
General Window ...................................................................................................... 28
System Time Window ................................................................................................ 33
Syslog & SNMP Window .............................................................................................. 34
Wireless Page ............................................................................................................ 36
RF Window ............................................................................................................ 36
wIDS/wIPS Window ................................................................................................... 40
Performance Optimization Window ............................................................................... 43
Access Page .............................................................................................................. 44
Authentication Window ............................................................................................. 45
Customized Portal Page Panel ..................................................................................... 48
Customized Portal Page – Login by Account ...................................................................... 49
Customized Portal Page – Login by Access Code ................................................................. 49
Customized Portal Page – Login by Terms of Use ................................................................ 49
Black List & White List Window .................................................................................... 50
Access Control List Window......................................................................................... 53
Network Page............................................................................................................ 54
5  WLAN Configuration ................................................................................................ 55
Create New WLAN ...................................................................................................... 55

Product specificaties

Merk:	Alcatel-Lucent
Categorie:	Access point
Model:	AP1251
Kleur van het product:	Wit
Gewicht:	2230 g
Breedte:	243 mm
Diepte:	243 mm
Hoogte:	85 mm
Gewicht verpakking:	4025 g
Breedte verpakking:	344 mm
Diepte verpakking:	341 mm
Hoogte verpakking:	220 mm
Internationale veiligheidscode (IP):	IP67
LED-indicatoren:	Ja
Plaatsing:	Pole, Wall
USB-connectortype:	Micro-USB
Aantal USB 2.0-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
Vermogensverbruik (max):	11.8 W
Certificering:	CB, cTUVus, FCC, CE, RoHS, REACH, WEEE
Modulatie:	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Netwerkstandaard:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3af
Ondersteunde beveiligingsalgoritmen:	AES, SSID, TKIP, WEP
Antenne versterkingsniveau (max):	8.46 dBi
Aantal gebruikers:	512 gebruiker(s)
Temperatuur bij opslag:	-40 - 85 °C
Intern:	Nee
Reset button:	Ja
Spanning:	48 V
Maximale overdrachtssnelheid van gegevens:	1267 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Quality of Service (QoS):	Ja
Wifi Multimedia (WMM)/(WME):	Ja
Power over Ethernet (PoE):	Ja
Antennefuncties:	Ingebouwde antenne
Automatische kanaalselectie:	Ja
Bedrijfstemperatuur (T-T):	-40 - 65 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Code geharmoniseerd systeem (HS):	85176990
Aantal SSID-ondersteuningen:	16
Syslog:	Ja
