Installation Manual

To installers:

•After installation is completed, be sure to hand the

accessories to the customer.

NOTE:

•The illustrations and images used in this manual may

differ from the actual ones.

HTML manual

https://www.aip-info.net/file/manual/j/JV-1MD/JV-

1MD_INS/JV-1MD_INS_EN/content/

Table of contents

Package contents ............................................. 2

Precautions ....................................................... 2

Part names and functions ............................... 3

Wiri ng................................................................ 5

Precautions for wiring .......................................... 5

Wiring diagram and specifications ....................... 6

Before installation ............................................ 7

Precautions for installation ................................... 7

Door station mounting positions and image view

area 8.....................................................................

Mounting ........................................................... 8

JV-1MD ................................................................ 8

JV- DV................................................................ 10

JV-DVF .............................................................. 11

After installation ............................................. 11

Check after installation .......................................11

Installer settings ................................................. 12

Privacy notice ................................................. 12

Issue date: Dec. 2023 FK2966 1223 (H1.00) DL GZ 65292 Ⓐ

JVS-1V (A set including JV-1MD, JV-DV and power supply)

JVS-1F (A set including JV-1MD, JV-DVF and power supply)

JV-1MD (Hands free color video intercom master monitor station)
